Attribute	Value
Base Tube Material	N04400, N08800, N08810, N08811, N08825
Length	Max 34M/PC
Fin Wall thickness	~0.3mm
Fin pitch	0.6-2
Fin height	＜1.6mm
Product Name	Nickel Alloy Extruded Fin Tube

Product Description

ASTM B163 N08825 Extruded Fin Tube Chemical Composition

Grade	Ni	Cu	Mo	Fe	Mn	C	Si	S	Cr	Al	Ti
N08825	38.0-46.0	1.5-3.0	2.5-3.5	22.0Mins	1.00	0.05	0.05	0.5	19.5-23.5	0.2	0.6-1.2

ASTM B163 N08825 Extruded Fin Tube FAQ

1. What is ASTM B163 N08825?

ASTM B163 is a standard specification for seamless nickel and nickel alloy condenser and heat-exchanger tubes.
N08825 (Incoloy 825) is a nickel-iron-chromium alloy with additions of molybdenum and copper, designed for corrosion resistance in a wide range of environments.

2. What are the key properties of N08825?

Corrosion Resistance: Excellent resistance to both reducing and oxidizing acids, stress-corrosion cracking, and pitting.
High Temperature Strength: Good mechanical properties at elevated temperatures.
Oxidation Resistance: Resists oxidation and carburization at high temperatures.
Weldability: Can be welded using common welding techniques.

3. What are the advantages of using ASTM B163 N08825 extruded fin tubes?

Enhanced Heat Transfer: The fins increase the surface area, improving heat transfer efficiency.
Corrosion Resistance: Suitable for harsh environments, including those with acidic and corrosive media.
Durability: High strength and resistance to thermal fatigue make them suitable for high-temperature applications.
Long Service Life: The material's resistance to corrosion and oxidation extends the lifespan of the tubes.

4. What are the typical applications of ASTM B163 N08825 extruded fin tubes?

Chemical Processing: Heat exchangers, condensers, and reactors in corrosive environments.
Petrochemical Industry: Used in refineries and petrochemical plants for heat recovery and process heating.
Power Generation: Condensers and heat exchangers in power plants.
Marine Applications: Heat exchangers in seawater environments due to excellent corrosion resistance.

5. What are the manufacturing standards for ASTM B163 N08825 extruded fin tubes?

Material Composition: Must comply with the chemical composition requirements for N08825.
Mechanical Properties: Must meet the tensile strength, yield strength, and elongation requirements specified in ASTM B163.
Dimensional Tolerances: Must adhere to the dimensional standards for seamless tubes and fin dimensions.
Testing and Inspection: Includes non-destructive testing (NDT), hydrostatic testing, and visual inspection to ensure quality and integrity.

6. What are the considerations for selecting ASTM B163 N08825 extruded fin tubes?

Operating Environment: Consider the chemical composition, temperature, and pressure of the operating environment.
Heat Transfer Requirements: Ensure the fin design meets the heat transfer efficiency needs.
Mechanical Strength: Verify that the tube can withstand the mechanical stresses of the application.
Compliance with Standards: Ensure the tubes meet the relevant industry standards and specifications.

7. How do you maintain ASTM B163 N08825 extruded fin tubes?

Regular Inspection: Periodic inspection for signs of corrosion, erosion, or mechanical damage.
Cleaning: Regular cleaning to remove fouling and deposits that can reduce heat transfer efficiency.
Monitoring: Continuous monitoring of operating conditions to detect any deviations that could affect tube performance.
