Name: Air Cooler Stainless Steel Extruded Fin Pipe ASTM A269 TP304 With Al1060
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: TP304,TP316L
Price: 10000.00 USD
Availability: InStock

Brand Name:	Yuhong
Model Number:	TP304,TP316L
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Material:

ASME SA269 TP304

Fin Type:

Extruded

Fin Thk:

0.4mm

Fin Material:

Al1060, Al1100

Application:

Heat Exchanger, Air Cooler

Test:

HT, ET

Highlight:

Stainless Steel Extruded Fin Pipe

Air Cooler Extruded Fin Pipe

ASTM extruded fin tubes

Product Description

Air Cooler Stainless Steel Extruded Fin Pipe ASTM A269 TP304 With Al1060

Product Specifications

Material	ASME SA269 TP304
Fin Type	Extruded
Fin Thickness	0.4mm
Fin Material	Al1060, Al1100
Application	Heat Exchanger, Air Cooler
Test	HT, ET

Key Features

Base Tube Material: ASTM A269 TP304 Stainless Steel - Austenitic stainless steel offering excellent corrosion resistance and durability in high-temperature environments.
Fin Material: A1060 Aluminum - Provides superior thermal conductivity, lightweight properties, and corrosion resistance with extruded fins for enhanced heat transfer.
Application: Ideal for air cooler systems requiring efficient heat exchange and corrosion resistance in demanding industrial environments.

Technical Specifications

Property	Base Tube (ASTM A269 TP304)	Fin Material (A1060 Aluminum)
Outer Diameter (OD)	12.7 mm - 50 mm	-
Wall Thickness	1.2 mm - 3.0 mm	-
Fin Thickness	-	0.4 mm
Fin Height	-	12 mm - 35 mm
Fin Type	-	Extruded
Fin Attachment	Mechanically bonded	Extruded onto the tube

Chemical Composition

Element	ASTM A269 TP304 Stainless Steel	A1060 Aluminum
Carbon (C)	0.08% (max)	0.05% (max)
Manganese (Mn)	2.00% (max)	0.05% (max)
Phosphorus (P)	0.045% (max)	0.05% (max)
Sulfur (S)	0.030% (max)	0.05% (max)
Chromium (Cr)	18.00% - 20.00%	-
Nickel (Ni)	8.00% - 10.50%	-
Aluminum (Al)	-	99.6% (min)

Mechanical Properties

Property	ASTM A269 TP304 Stainless Steel	A1060 Aluminum
Tensile Strength	520 - 720 MPa	110 - 140 MPa
Yield Strength	215 MPa (min)	70 MPa (min)
Elongation	≥ 40%	≥ 15%
Hardness	150 - 200 HB	30 - 50 HB

Product Advantages

Enhanced Heat Transfer: Extruded aluminum fins maximize surface area for superior heat exchange efficiency.
Corrosion Resistance: TP304 stainless steel and A1060 aluminum combination provides excellent protection in harsh environments.
Durability: High-temperature oxidation resistance and mechanical strength ensure long service life.
Lightweight Construction: Aluminum fins reduce overall weight while maintaining structural integrity.
Operational Efficiency: Optimized for air cooler systems in demanding industrial applications.

Applications

Air-cooled heat exchangers in power generation, oil refining, and manufacturing
Cooling towers for industrial heat dissipation
HVAC systems for temperature regulation
Industrial heat exchangers requiring high heat transfer rates
