Name: Carbon Steel ASTM A179 Extruded Fin Tube With Al-1060 For Air Cooled Condenser
Brand: YUHONG HOLDING GROUP CO., LTD
SKU: ASTM A179
Price: 10000.00 USD
Availability: InStock

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Tube Material:

A179

Fin Material:

Al1060, Al1100

Fin Type:

Extruded

Fin Height:

15.875mm

Fin Thickness:

0.4mm

FPI:

Highlight:

A179 extruded finned tube

Carbon Steel extruded finned tube

Al1100 extruded finned tubes

Product Description

Carbon Steel ASTM A179 Extruded Fin Tube With Al-1060 For Air Cooled Condenser

Product Specifications

Tube Material	A179
Fin Material	Al1060, Al1100
Fin Type	Extruded
Fin Height	15.875mm
Fin thickness	0.4mm
FPI	10

Key Features

Base Tube Material: Carbon Steel A179, offering good strength, heat transfer properties, and cost-effectiveness for air-cooled condenser systems.
Fin Material: Aluminum 1060 provides excellent thermal conductivity, corrosion resistance, and light weight for high-efficiency heat transfer.
Fin Type: Extruded fins enhance heat dissipation by maximizing surface area for air-to-surface heat exchange.
Application: Specifically engineered for air-cooled condensers in industrial, HVAC, and power generation systems.

Technical Specifications

Property	Base Tube (Carbon Steel A179)	Fin Material (Aluminum 1060)
Outer Diameter (OD)	19.05 mm - 50.8 mm	Customizable based on design
Wall Thickness	1.2 mm - 3.0 mm	-
Fin Thickness	-	0.5 mm - 1.5 mm
Fin Height	-	10 mm - 40 mm
Fin Attachment	Extruded and bonded to base tube	-

Chemical Composition

Element	Carbon Steel A179 (Base Tube)	Aluminum 1060 (Fin Material)
Carbon (C)	≤ 0.10%	≤ 0.03%
Manganese (Mn)	0.30% - 0.60%	≤ 0.03%
Phosphorus (P)	≤ 0.035%	-
Sulfur (S)	≤ 0.035%	-
Chromium (Cr)	≤ 0.30%	-
Nickel (Ni)	≤ 0.40%	-
Aluminum (Al)	-	≥ 99.0%

Mechanical Properties

Property	Carbon Steel A179 (Base Tube)	Aluminum 1060 (Fin Material)
Tensile Strength	335 - 485 MPa	70 - 110 MPa
Yield Strength	≥ 205 MPa	35 - 55 MPa
Elongation	≥ 30%	≥ 20%

Advantages

Efficient Heat Transfer: Extruded fin design maximizes surface area for improved heat dissipation.
Corrosion Resistance: Aluminum 1060 fins provide long-lasting durability in air-cooled systems.
Cost-Effective: Carbon steel A179 base tube offers good mechanical properties at competitive costs.
Lightweight and Durable: Aluminum fins reduce system weight while maintaining strength and efficiency.

Applications

Air-Cooled Condensers for HVAC systems, petrochemical plants, and power generation plants
Chillers in industrial refrigeration systems
Heat exchangers requiring efficient air-based heat dissipation
HVAC cooling systems for residential and commercial buildings
