Brand Name:	YUHONG
Model Number:	Extruded Tube, Fin Tube,Extruded
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply - Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material:

A179 , SA179

Base Tube Standard:

ASTM A179, ASME SA179

Fin Type:

Extruded Type

Application:

Industrial Air Conditioning Applications、Industrial Refrigeration、 Cooling Systems、Heater Applications

Supply Ability:

10000 Tons/Month

Highlight:

Heat Exchanger Extruded Fin Tube

Extruded Fin Tube A179

ASTM finned tubes embedded extruded

Product Description

Air Cooler Heat Exchanger Carbon Steel Extruded Fin Tube ASTM A179

Product Specifications

Attribute	Value
Base Tube Material	A179, SA179
Base Tube Standard	ASTM A179, ASME SA179
Fin Type	Extruded Type
Application	Industrial Air Conditioning Applications, Industrial Refrigeration, Cooling Systems, Heater Applications

Product Description

Carbon Steel Fin Tube, Extruded Fin Type, ASTM A179, Air Cooler, Heat Exchanger

Structural Features of Extruded Fin Tube

Integral Formation: Fins and base tube are integrally formed through extrusion, creating a tight bond with low thermal resistance and high heat transfer efficiency.
Diverse Fin Shapes: Available in flat, corrugated, and serrated designs to optimize fluid flow and heat transfer performance.
Material Options: Base tube materials include carbon steel, stainless steel, and copper. Fins typically use high-conductivity materials like aluminum or copper.

Manufacturing Process

Extrusion Molding: Metal is heated and pressed through molds to form precise fin dimensions with high accuracy.
Post-Processing: Includes heat treatment to relieve stresses and improve mechanical properties, plus surface treatments for enhanced corrosion resistance.

Key Advantages

High Heat Transfer Efficiency
Superior Mechanical Strength
Excellent Corrosion Resistance
Easy Cleaning and Maintenance

Common Applications

Air Coolers
Drying Equipment
Heat Sinks
Heat Exchangers

Material Properties

Chemical Composition

Carbon (C)	Manganese (Mn)	Phosphorus (P)	Sulfur (S)
0.06% - 0.18%	0.27% - 0.63%	Max 0.035%	Max 0.035%

Mechanical Properties

Tensile Strength	Yield Strength	Elongation	Hardness
Min 325 MPa (47,000 psi)	Min 180 MPa (26,000 psi)	Min 35%	Max 72 HRB
