Carbon Steel A179 Extruded Finned Tube Suppliers ASTM

Brand Name:	YUHONG
Model Number:	ASTM A179
MOQ:	Depend the size of finned tubes, 50-100PC
Price:	30-10000 USD
Packaging Details:	Ply-wooden Case With Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Product:

Fin Tubes Or Finned Tube

Standard:

ASTM A179

Material:

Base Tubes A179 And AL1060 Fins

Type:

Extruded Finned Tubes

Length:

According To Clients' Need

Size And Details:

According To Clients' Need

Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators / Air Cooler, Etc

Packing:

Ply-wooden Case With Iron Frame

Supply Ability:

1000 tons/month

Highlight:

A179 extruded finned tube suppliers

Carbon Steel extruded finned tube suppliers

ASTM extruded tube fins

Product Description

Carbon Steel A179 Extruded Finned Tube Suppliers ASTM

Product Specifications

Attribute	Value
Product	Fin Tubes or Finned Tube
Standard	ASTM A179
Material	Base Tubes A179 and AL1060 Fins
Type	Extruded Finned Tubes
Length	Customizable to client requirements
Size and details	Customizable to client requirements
Use	Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators / Air cooler
Packing	Ply-wooden Case With Iron Frame

Product Description

Extruded Fin Tubes Carbon Steel A179 With AL1060 Fins Tubos Aletados For Radiadores

Base Tube Details (Generally with min. wall thickness)

ASTM A179 specification covers minimum-wall-thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus.

Chemical Composition (%) max

Grade	C	Mn	P	S
A179	0.06-0.18	0.27-0.63	0.035	0.035

Mechanical Properties

Grade	Tensile Strength min	Yield Strength min	Elongation in 2" or 50mm min
A179	47ksi (325 MPa)	26ksi (180 MPa)	35%

Definition

Extruded finned tubes are bimetallic tubes whose outer aluminium surface is finned by cold plastic deformation. The general materials of base tubes about the extruded finned tube are carbon steel, copper, alloy, stainless steel; the general materials of fins about the extruded finned tube are copper, aluminum 1060/1070, aluminum alloy 6063/6061.

Therefore, it is generally divided into four categories: steel aluminum composite finned tubes; copper aluminum composite finned tubes; pure aluminum composite finned tubes, pure copper composite finned tube.

Advantages

Composite finned tubes have the following characteristics:

High heat transfer performance, small contact thermal resistance
The contact area between the fin and the pipe is large, the fit is tight and reliable
Good corrosion resistance, stable long-term use performance
Highly cost effective
The fin has good rigidity and is not easy to deform

The processing technology of steel and aluminum cold-rolled fin tube consists of aluminum tube and steel pipe being processed into bimetal composite tube, and then forming fin after mechanical cold rolling. Based on the physical characteristics of aluminum tube, the tube with steel tube as the core and the cold rolled aluminum fin are made into a finned tube. Widely used in steel, petroleum, chemical industry, machinery, shipbuilding, power stations and hospitals and food industries.
