Extruded Fin Tube ASTM A312 TP304 For Heat Exchangers Boilers

Brand Name:	YUHONG
Model Number:	ASTM A312 TP304
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply - Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Standard:

ASTM A312,ASME SA312

Base Tube Material Grade::

TP304,TP304L,TP304H,TP321

Fin Type:

Extruded Fin Tube

Fin Material:

Aluminum , Copper , Stainless Steel , Carbon Steel

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A312 Extruded Fin Tube

Heat Exchangers Extruded Fin Tube

Boilers Extruded Fin Tube

Product Description

Extruded Fin Tube ASTM A312 TP304 For Heat Exchangers Boilers

Product Specifications

Attribute	Value
Base Tube Material Standard	ASTM A312, ASME SA312
Base Tube Material Grade	TP304, TP304L, TP304H, TP321
Fin Type	Extruded Fin Tube
Fin Material	Aluminum, Copper, Stainless Steel, Carbon Steel

Product Description

Extruded Fin Tube, ASTM A312 TP304 For Heat Exchanger

ASTM A312 specifies requirements for the chemical composition, mechanical properties, and manufacturing processes, ensuring high-quality stainless steel pipes. ASTM A312 materials maintain strength and integrity at elevated temperatures, making them ideal for high-temperature applications such as boilers and heat exchangers.

TP304L offers excellent resistance to corrosive environments, making it suitable for chemical processing and marine applications. The material maintains good strength and stability at elevated temperatures, essential for heat exchange applications. P304L is easily weldable, allowing for effective fabrication of complex geometries beneficial for manufacturing fin tubes.

Chemical Composition

ASTM A312 TP304 Chemical Composition (%)

Result

≤0.08%

≤0.75%

≤2.00%

≤0.045%

≤0.030%

18.0%-20%

Fin Tube Specifications

Type	Description	Base tube O.D. (mm)	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tube	16-63	2.1-5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6-10	<17	0.2-0.4
Low fin tube	T-type fin tube	10-38	0.6-2	<1.6	~0.3
Bamboo tube	Corrugated tube	16-51	8~30	<2.5	/
Wound	L/KL/LL type fin tube	16-63	2.1-5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3~25	5~30	0.8-3

Applications

Heat Exchangers
Condensers
Boilers
Chillers
Radiators
Evaporators
Cooling Towers
Chemical Process Equipment
