Carbon Steel Fin Tube , Extruded Type , ASTM A179 with Aluminum 6063 , Air Cooler / Dry Kiln application

Brand Name:	YUHONG
Model Number:	Extruded Fin Tube , Fin Tube , Extruded
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ASME , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Base Tube Material:

ASTM A179 , ASME SA179 , ST35.8

Base Tube Standard:

ASTM A179 , ASME SA179 , DIN 17175

Fin Type:

Extruded Type

Fin Material:

ASTM B221, ASME SB221, ASTM B241 , ASME SB241

Application:

HVAC Systems, Refrigeration, Air Conditioning, Air Cooled Heat Exchangers, Waste Heat Recovery,

Fin Material Grade:

6061, 6063, 1050, 1060, 1100

Supply Ability:

10000 tons/month

Highlight:

aluminum steel fin tube

aluminum extruded fin tube

carbon steel steel fin tube

Product Description

Carbon Steel Fin Tube, Extruded Type, ASTM A179 with Aluminum 6063 for Air Cooler/Dry Kiln Applications

Product Specifications

Attribute	Value
Base Tube Material	ASTM A179, ASME SA179, ST35.8
Base Tube Standard	ASTM A179, ASME SA179, DIN 17175
Fin Type	Extruded Type
Fin Material	ASTM B221, ASME SB221, ASTM B241, ASME SB241
Application	HVAC systems, Refrigeration, Air Conditioning, Air Cooled Heat Exchangers, Waste Heat Recovery
Fin Material Grade	6061, 6063, 1050, 1060, 1100

Product Description

High-performance carbon steel fin tubes with extruded aluminum fins, manufactured to ASTM A179 standards. Designed for optimal heat transfer in demanding industrial applications including air coolers and dry kilns.

Yuhong Holding Group brings over 35 years of expertise in steel pipe and fin tube manufacturing, serving global markets in petrochemical, oil refinery, furnace, heating, boiler, and heat exchanger applications. Our products are exported to more than 85 countries worldwide.

Material Specifications

ASME SA179 Chemical Composition (%)

C	Si	Mn	P	S	Cr	Ni	Mo	TI	Nb	Cu	Al	V	Co	Fe	Result
0.06~0.18	/	0.27~0.63	≤0.035	≤0.035	/	/	/	/	/	/	/	/	/	/

ASME SA179 Tensile Test ASTM A370-20

Tensile Strength: Rm (Mpa)	Yield Strength: Rp 0.2(Mpa)	Elongation: A (%)
≥325	≥180	≥35

Manufacturing Advantages

20,000 square meters production facility with 20 finning machines

Daily extrusion capacity of 30,000 meters

Strategic location near Shanghai Port (less than 2 hours drive)

High rigidity for extreme temperature and pressure conditions

Applications

Heat Exchangers for HVAC, refrigeration, and industrial processes

Air Cooled Heat Exchangers in power plants and refineries

Process heating and cooling in chemical, food, and pharmaceutical industries

Power generation systems including steam condensers and boilers

Waste heat recovery systems for improved energy efficiency

Refrigeration and freezing applications

Aerospace and automotive cooling systems
