Extruded Fin Tube

Extruded Fin Tube , ASTM A249 TP304 Stainless Steel Extruded Fin Tube , Air Cooler , Cooling Tower

All Category

Stainless Steel Heat Exchanger Tube

Duplex Stainless Steel Heat Exchanger Tube

Super Duplex Stainless Steel Heat Exchanger Tube

Nickel Alloy Steel Heat Exchanger Tube

Copper Alloy Steel Heat Exchanger Tube

Titanium Alloy Steel Heat Exchanger Tube

Alloy Steel Heat Exchanger Tube

Carbon Steel Heat Exchanger Tubes

Nickel Alloy Steel Boiler Tube

Duplex Stainless Steel Boiler Tube

Carbon Steel Boiler Tube

Sales Dept. (Marketing Director)

sales@steelseamlesspipe.com

+8613819835483

Contact Now

Extruded Fin Tube , ASTM A249 TP304 Stainless Steel Extruded Fin Tube , Air Cooler , Cooling Tower

Brand Name:	YUHONG
Model Number:	Extruded Fin tube , Aluminum Extruded Fin tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

TP304

Base Tube Material Standard:

ASTM A249, ASME SA249

Type:

Straight Tube , U Bend Tube , Coil Tube

Application:

Air Cooler, Cooling Tower, Heat Exchanger, Condenser

Fin Type:

Extruded Fin Tube , Aluminum Extruded Fin Tube , Fin Tube

Fin Material:

Aluminum , Copper , Stainless Steel , Carbon Steel

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A249 Extruded Fin Tube

Extruded Fin Tube TP304

ASME Stainless Steel Tube

Product Description

Extruded Fin Tube, ASTM A249 TP304 Stainless Steel Extruded Fin Tube for Air Coolers & Cooling Towers

Product Specifications

Base Tube Material Grade	TP304
Base Tube Material Standard	ASTM A249, ASME SA249
Type	Straight Tube, U Bend Tube, Coil Tube
Application	Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type	Extruded Fin tube, Aluminum Extruded Fin tube, Fin tube
Fin Material	Aluminum, Copper, Stainless Steel, Carbon Steel

Product Description

ASTM A249 TP304 Extruded Fin Tubes are cold worked welded tubes manufactured from austenitic stainless steel, designed for high-performance heat transfer applications. These tubes combine excellent corrosion resistance with superior high-temperature strength, making them ideal for demanding industrial environments.

Key Features

Manufactured to ASTM A249/ASME SA249 specifications

Available in straight, U-bend, and coil tube configurations

Multiple fin material options including aluminum, copper, and stainless steel

Excellent pressure bond between fin and base tube

Superior heat transfer efficiency

Technical Specifications

Equivalent Materials

Grade	UNS No	Old British	Euronorm	SS	JIS
TP304	S30400	304S31	58E	1.4301	SUS 304

Chemical Composition

C	Si	Mn	Cr	Ni	S	P	Fe
0.08	1	2	18-20	8-11	0.03	0.045	Bal.

Mechanical Properties

Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness (Rockwell B max)	Hardness (Brinell HB max)
515	205	40	92	201

Applications

Heat Exchangers

Condensers

Power Plants

Steam Generators

Petrochemical Industries

Marine Applications

Refrigeration Equipment
