Carbon Steel ASME SA209 T1a Boiler Tube For Power Plants Boilers

Brand Name:	YUHONG
Model Number:	Boiler Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

Standard:

ASTM A209 , ASME SA209

External Diameter:

>38.1

Ends:

PE , BE

Tube Material:

Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon

Application:

Boiler

Supply Ability:

10000 Tons/Month

Highlight:

ASME SA209 T1a Boiler Tube

Carbon Steel Boiler Tube

Power Plants Boiler Tube

Product Description

Carbon Steel ASME SA209 T1a Boiler Tube For Power Plants Boilers

Product Specifications

Attribute	Value
Material Grade	T1a
Standard	ASTM A209, ASME SA209
External Diameter	>38.1
Ends	PE, BE
Tube Material	Nickel Alloy, Alloy, Stainless Steel, Duplex Stainless Steel, Carbon
Application	Boiler

Product Description

Carbon Steel ASME SA209 T1a Boiler Tube is engineered for superior performance in high-temperature environments, making it the ideal choice for power plant boilers and superheaters.

The chromium-enhanced composition provides exceptional oxidation resistance, ensuring long-term durability in demanding heat applications. These tubes maintain structural integrity under high-pressure conditions, making them perfect for steam generation systems and other pressurized industrial processes.

With excellent heat transfer properties, SA209 T1a tubes optimize efficiency in boilers, heat exchangers, and economizers, delivering reliable performance in critical industrial applications.

Chemical Composition

Carbon: 0.30% - 0.40%
Manganese: 0.60% - 0.90%
Phosphorus: ≤ 0.035%
Sulfur: ≤ 0.035%
Silicon: 0.20% - 0.40%
Copper: ≤ 0.35%
Chromium: 0.80% - 1.25%
Nickel: ≤ 0.50%

Mechanical Properties

Tensile Strength: 485 - 620 MPa (70 - 90 ksi)
Yield Strength: 275 MPa (40 ksi) min.
Elongation: 20% min. (in 8 inches)
Hardness: 170 HB (Brinell Hardness) max.
Impact Toughness: Designed for good toughness at elevated temperatures

Key Applications

Power Generation Plants: Essential for superheaters, reheaters, and boiler drums where high-temperature steam is generated, offering reliable performance under continuous thermal stress.

Heat Exchangers: Ideal for high-efficiency heat transfer systems due to superior thermal conductivity and structural strength.

Marine Boilers: Provides dependable performance in shipboard boiler systems, withstanding the unique challenges of marine environments.

Industrial Furnaces: Used in high-temperature furnaces and kilns where efficient heat transfer and mechanical durability are critical.
