ASME SA423 GR1 Carbon Steel Boiler Tube For Boilers Steam Generators

Brand Name:	YUHONG
Model Number:	Boiler Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

Standard:

ASTM A423 , ASME SA423

External Diameter:

>38.1

Ends:

PE , BE

Tube Material:

Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon

Application:

Boiler

Supply Ability:

10000 Tons/Month

Highlight:

Steam Generators Carbon Steel Boiler Tube

Boilers Carbon Steel Boiler Tube

ASME SA423 GR1 Carbon Boiler Tube

Product Description

ASME SA423 GR1 Carbon Steel Boiler Tube For Boilers Steam Generators

Product Specifications

Attribute	Value
Material Grade	GR1
Standard	ASTM A423, ASME SA423
External Diameter	>38.1
Ends	PE, BE
Tube Material	Nickel Alloy, Alloy, Stainless Steel, Duplex Stainless Steel, Carbon
Application	Boiler

Product Description

ASME SA423 GR1 Carbon Steel Boiler Tube For Boilers, Steam Generators

ASME SA423 Gr. 1 is a carbon steel alloy specifically formulated for high-pressure and temperature applications in steam boilers, heat exchangers, and other critical systems. The material primarily consists of carbon with trace elements like manganese, silicon, phosphorus, and sulfur.

This material conforms to the ASME SA423 specification for carbon steel tubes used in heat exchangers, superheaters, and other heat transfer equipment in power plants and industrial applications. SA423 Gr. 1 tubes exhibit excellent tensile strength, yield strength, and toughness at elevated temperatures, designed to withstand high-pressure conditions with good resistance to internal and external stresses.

Chemical Composition

Carbon: 0.18% - 0.23%
Manganese: 0.30% - 0.60%
Phosphorus: ≤ 0.035%
Sulfur: ≤ 0.035%
Silicon: 0.10-0.35%
Copper: ≤ 0.25%
Chromium: ≤ 0.20%
Nickel: ≤ 0.20%

Mechanical Properties

Tensile Strength: 415 - 550 MPa (60 - 80 ksi)
Yield Strength: 205 MPa (30 ksi) min.
Elongation: 30% min. (in 8 inches)
Hardness: 150 HB (Brinell Hardness) max.
Impact Toughness: Designed to withstand impacts at elevated temperatures

Applications

Boiler Systems
Heat Exchangers
Pressure Vessels
Power Plants
Chemical and Petrochemical Industries
Waste Heat Recovery Systems
Marine and Shipbuilding
Industrial Heating Equipment
