ASTM A213 T5 Alloy Steel Seamless Tube For Boilers Application

Brand Name:	YuHong
Model Number:	ASTM A213 T5
MOQ:	200~500 KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Plastic Caps on Tube's Both Ends
Payment Terms:	T/T, L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO, ABS, BV, ISO, ASTM, SGS

Product Name:

Alloy Steel Seamless Tube

Tube Specification:

ASTM A213 / ASME SA213

Tube Material:

Tube's OD&WE:

Depend On Customer

Tube's End:

Plain End

Tube's Length:

Depend On Customer

Application:

Boiler, Superheater, And Heat-Exchanger

Supply Ability:

According to Clients' requirements

Highlight:

Boilers Alloy Steel Seamless Tube

Alloy Steel Seamless Tube For Boilers

ASTM A213 T5 seamless boiler tube

Product Description

ASTM A213 T5 Alloy Steel Seamless Tube For Boilers Application

Product Specifications

Attribute	Value
Product Name	Alloy Steel Seamless Tube
Tube Specification	ASTM A213 / ASME SA213
Tube material	T5
Tube's OD&WE	Depend on Customer
Tube's End	Plain end
Tube's length	Depend on Customer
Application	Boiler, Superheater, and Heat-Exchanger

Product Overview

ASTM A213 T5 seamless Boiler Tubes are specification-grade seamless ferritic and austenitic alloy steel tubes designed for boiler, superheater, and heat-exchanger applications. Manufactured from chromium molybdenum alloy steel T5, these tubes offer exceptional high-temperature strength, corrosion resistance, and weldability.

Key Advantages

High-temperature strength: Chromium molybdenum alloy steel composition provides excellent performance in high-temperature environments
Corrosion resistance: Superior resistance against steam, water, chemicals, and gases
Excellent weldability: Easy joining without cracking or distortion
Exceptional durability: Withstands extreme operating conditions
Cost-effective solution: Minimal maintenance requirements reduce downtime

Technical Specifications

Chemical Composition

Carbon (C): 0.15 max
Manganese (Mn): 0.30-0.60
Phosphorus (P): 0.025 max
Sulfur (S): 0.025 max
Silicon (Si): 0.50 max
Chromium (Cr): 4.00-6.00
Molybdenum (Mo): 0.45-0.65

Mechanical Properties

Tensile strength: 415 MPa (min)
Yield strength: 205 MPa (min)
Elongation: 30% (min)
Hardness: HRB 163 (max)

Note: Mechanical properties may vary based on manufacturing process and heat treatment.

Industrial Applications

Power generation: Boilers, superheaters, and reheaters in thermal power plants
Oil and gas: Refineries, pipelines, and steam injection operations
Chemical processing: Reactors, heat exchangers, and furnaces
Petrochemical: Equipment requiring durability and corrosion resistance
Aerospace: Engine components and heat exchangers
