SA213 TP304L is a low-carbon austenitic stainless steel (18% Cr, 8% Ni, low C) used in U-bend boiler tubes for high-corrosion resistance and flexibility in heat exchangers.

Primary Applications

Heat Exchangers & Condensers - Shell & tube heat exchangers (U-bends allow thermal expansion). Surface condensers in power plants (resists steam/condensate corrosion).
Boilers & Superheaters - Recovery boilers (handles flue gas condensates). Low-pressure steam boilers (where chloride stress corrosion is a concern).
Petrochemical & Refining - Reboilers, feedwater heaters (resists acidic/alkaline conditions). Refinery heat recovery systems (exhaust gas applications).
Food & Pharmaceutical Processing - Sanitary heat exchangers (non-reactive, easy to clean).
Marine & Desalination - Desalination plant tubing (resists saltwater pitting/crevice corrosion).

Why Use SA213 TP304L U-Bend Tubes?

✔ Excellent corrosion resistance (vs. carbon steel in acidic/chloride environments)
✔ Low carbon content (0.03% max) - prevents sensitization & intergranular corrosion
✔ Good weldability - no post-weld heat treatment required
✔ High ductility - U-bends withstand thermal expansion stresses
✔ Oxidation resistance up to ~800°C (1472°F)

Comparison with Other Grades

Grade	Key Features	Best For
TP304L	Low carbon, general corrosion resistance	Most heat exchangers, food/pharma
TP316L	Added Mo (2-3%), better chloride resistance	Marine, desalination, harsh chemicals
TP321	Ti-stabilized, resists sensitization	High-temp exhausts, aircraft
TP347	Nb-stabilized, superior creep resistance	Superheaters, high-pressure steam

Common FAQs

Can TP304L handle high-pressure steam?

Yes, but for >500°C (932°F), TP321/TP347 is preferred due to better creep strength.

Why U-bend instead of straight tubes?

Absorbs thermal expansion (reduces stress on tube sheets). Compact design (saves space in heat exchangers).

How to prevent stress corrosion cracking (SCC)?

Avoid chloride exposure >60°C (140°F). Use TP316L if chlorides are present.

What's the max operating temperature?

Continuous: ~800°C (1472°F) (oxidizing environments). For pressure service: ~425°C (797°F) per ASME limits.

How to inspect U-bend tubes?

Dye penetrant (PT) for surface cracks. Radiography (RT) for internal defects.

Tags:

TP304L stainless steel boiler tube

SA213 stainless boiler tube

Condensers u bend boiler tube

ASME SA423 GR.1 Low Alloy Steel Welded Tube For Boiler And Superheater

Get Best Price

ASTM B407 NO8811 Nickel Alloy Steel Tube For Power Generation

Get Best Price

N06600 ASTM B167 Nickel Alloy Steel Seamless Tube For Power Generation

Get Best Price

ASTM A335 P5 Alloy Steel Seamless Boiler Tubes For High Temperature Service

Get Best Price

ASTM A192 Carbon Steel Seamless Boiler And Superheater Tubes

Get Best Price

ASME SB163 Boiler Monel 400 Tube For Annealing Furnace Cooler And Fired Heater

Get Best Price

ASME SA179 Carbon Steel Tube For Heat Exchangers Condensers

Get Best Price

T11 ASTM A213 Alloy Steel Seamless Boiler Tubes For High Temperature Service

Get Best Price

Products Details

Home > Products >

Boiler Tube

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers And Condensers

All Category

Studded Tube

Solid Fin Tube

Serrated Finned Tube

Embedded G Fin Tube

Extruded Fin Tube

Wound Fin Tube

Low Fin Tube

Square Fin Tube

Longitudinal Finned Tube

Enhanced Heat Transfer Tube

Fin Tube Support

Return Bend

Heat Exchanger Tube

Stainless Steel Heat Exchanger Tube

Duplex Stainless Steel Heat Exchanger Tube

Nickel Alloy Steel Heat Exchanger Tube

Copper Alloy Steel Heat Exchanger Tube

Titanium Alloy Steel Heat Exchanger Tube

Alloy Steel Heat Exchanger Tube

U Bend Heat Exchanger Tube

Carbon Steel Heat Exchanger Tubes

Boiler Tube

Nickel Alloy Steel Boiler Tube

Stainless Steel Boiler Tube

Alloy Steel Boiler Tube

Carbon Steel Boiler Tube

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers And Condensers

Brand Name:	YUHONG GROUP
MOQ:	1PC
Price:	Negotiable
Packaging Details:	WOODEN CASE WITH PLASTIC CAP
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Brand Name:

YUHONG GROUP

Tube Material:

A179, A106, A210

Length:

Max 34M/PC

O.D.:

6-50.8mm

W.T.:

0.5-15mm

Testing:

UT, ET, HT, PMI

Product Name:

Stinless Steel U Bend Boiler Tube

Minimum Order Quantity:

1PC

Price:

Negotiable

Packaging Details:

WOODEN CASE WITH PLASTIC CAP

Delivery Time:

According to the quantity

Payment Terms:

L/C,T/T

Supply Ability:

10000 tons/month

Highlight:

TP304L stainless steel boiler tube

SA213 stainless boiler tube

Condensers u bend boiler tube

Product Description

SA213 TP304L Stainless Steel U Bend Boiler Tube For Hot Water Boilers And Condensers

Product Specifications

Tube Material	A179, A106, A210
Length	Max 34M/PC
O.D.	6-50.8mm
W.T.	0.5-15mm
Testing	UT, ET, HT, PMI
Product Name	Stainless Steel U Bend Boiler Tube

ASME SA213 TP304L U-Bend Boiler Tube - Applications & Key Features

SA213 TP304L is a low-carbon austenitic stainless steel (18% Cr, 8% Ni, low C) used in U-bend boiler tubes for high-corrosion resistance and flexibility in heat exchangers.

Primary Applications

Heat Exchangers & Condensers - Shell & tube heat exchangers (U-bends allow thermal expansion). Surface condensers in power plants (resists steam/condensate corrosion).
Boilers & Superheaters - Recovery boilers (handles flue gas condensates). Low-pressure steam boilers (where chloride stress corrosion is a concern).
Petrochemical & Refining - Reboilers, feedwater heaters (resists acidic/alkaline conditions). Refinery heat recovery systems (exhaust gas applications).
Food & Pharmaceutical Processing - Sanitary heat exchangers (non-reactive, easy to clean).
Marine & Desalination - Desalination plant tubing (resists saltwater pitting/crevice corrosion).

Why Use SA213 TP304L U-Bend Tubes?

✔ Excellent corrosion resistance (vs. carbon steel in acidic/chloride environments)
✔ Low carbon content (0.03% max) - prevents sensitization & intergranular corrosion
✔ Good weldability - no post-weld heat treatment required
✔ High ductility - U-bends withstand thermal expansion stresses
✔ Oxidation resistance up to ~800°C (1472°F)

Comparison with Other Grades

Grade	Key Features	Best For
TP304L	Low carbon, general corrosion resistance	Most heat exchangers, food/pharma
TP316L	Added Mo (2-3%), better chloride resistance	Marine, desalination, harsh chemicals
TP321	Ti-stabilized, resists sensitization	High-temp exhausts, aircraft
TP347	Nb-stabilized, superior creep resistance	Superheaters, high-pressure steam

Common FAQs

Can TP304L handle high-pressure steam?

Yes, but for >500°C (932°F), TP321/TP347 is preferred due to better creep strength.

Why U-bend instead of straight tubes?

Absorbs thermal expansion (reduces stress on tube sheets). Compact design (saves space in heat exchangers).

How to prevent stress corrosion cracking (SCC)?

Avoid chloride exposure >60°C (140°F). Use TP316L if chlorides are present.

What's the max operating temperature?

Continuous: ~800°C (1472°F) (oxidizing environments). For pressure service: ~425°C (797°F) per ASME limits.

How to inspect U-bend tubes?

Dye penetrant (PT) for surface cracks. Radiography (RT) for internal defects.
