ASME SA213 TP347H Seamless Stainless Steel Boiler Tube For Petrochemical Industry

Brand Name:	YUHONG
Model Number:	Boiler Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

TP347H

Standard:

ASTM A213 , ASME SA213

External Diameter:

>38.1

Ends:

PE , BE

Tube Material:

Nickel Alloy , Alloy , Stainless Steel , Duplex Stainless Steel , Carbon

Application:

Boiler

Supply Ability:

10000 Tons/Month

Highlight:

ASME SA213 Stainless Steel Boiler Tube

Seamless Stainless Steel Boiler Tube

Petrochemical Industry Seamless Stainless Steel Tubing

Product Description

ASME SA213 TP347H Seamless Stainless Steel Boiler Tube For Petrochemical Industry

Product Specifications

Attribute	Value
Material Grade	TP347H
Standard	ASTM A213, ASME SA213
External Diameter	>38.1
Ends	PE, BE
Tube Material	Nickel Alloy, Alloy, Stainless Steel, Duplex Stainless Steel, Carbon
Application	Boiler

Product Description

ASME SA213 TP347H Seamless Stainless Steel Boiler Tube is a niobium-containing Cr-Ni austenitic stainless steel with excellent high-temperature strength and organizational stability. This material offers superior oxidation resistance and soothing reaction properties, along with excellent bending and welding characteristics, making it ideal for complex working conditions.

Chemical Composition

Grade	C	Cr	Ni	Mn	Si	P	S	Nb+Ta
TP347H	0.04-0.10%	17.0-19.0%	9.0-13.0%	2.0% max	0.75% max	0.045% max	0.030% max	8xC-1.00% max

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
TP347H	Minimum 515 MPa (75 ksi)	Minimum 205 MPa (30 ksi)	20% minimum in 50 mm	≤ 220 HB (Brinell Hardness)

Key Features

High-Temperature Strength: Ensures reliable performance in high-temperature applications
Oxidation Resistance: Provides excellent resistance to oxidation in demanding environments
Creep Resistance: High resistance to creep for long-term reliability under continuous high-temperature exposure
Durability: High tensile strength and toughness provide long service life in demanding conditions
Weldability: Good weldability allows for easy fabrication and repair of boiler tubes
Versatility: Suitable for a wide range of high-temperature and high-pressure applications

Applications

Petrochemical Industry

Refinery equipment processing high-temperature and high-pressure steam
Catalytic cracking units requiring high temperatures and corrosion resistance
High-temperature heat exchangers in petrochemical plants

Marine Applications

Marine boilers for steam generation on ships and submarines
Marine heat exchangers exposed to high-pressure steam
High-pressure steam systems in marine engine rooms

Oil and Gas Industry

Components in offshore platforms exposed to high temperatures and corrosive environments
Downhole tubing for oil and gas extraction requiring high-temperature strength
Refinery equipment processing sour gas and other corrosive substances at high temperatures
