Stainless Steel Boiler Tube, ASME SA213 TP316H, Super Heater Boiler Application

Brand Name:	YUHONG
Model Number:	ASTM A213
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Bundle + Cap , Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Material Grade:

TP316, TP316L , TP316H , 1.4401, 1.4404

Material Standard:

ASTM A213, ASME SA213, JIS G3459, EN10216-5, GOST 9941-81

ET, UT, HT, PT, PMI

Size OD:

31.75 ~ 165.2mm

Size Thickness:

2~20mm

Size Length:

Max.: 34m/pc

Supply Ability:

10000 tons/month

Highlight:

31.75mm Stainless Steel Boiler Tube

165.2mm Stainless Steel Boiler Tube

high Tensile Super Heater Boiler tube

Product Description

Stainless Steel Boiler Tube, ASME SA213 TP316H, Super Heater Boiler Application

Product Specifications

Attribute	Value
Material Grade	TP316, TP316L, TP316H, 1.4401, 1.4404
Material Standard	ASTM A213, ASME SA213, JIS G3459, EN10216-5, GOST 9941-81
NDT	ET, UT, HT, PT, PMI
Size OD	31.75 ~ 165.2mm
Size Thickness	2~20mm
Size Length	Max.: 34m/pc

Product Description

ASME SA-213 / SA-213M: Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes.

Below ASME SA213, it also contains many special grades including TP304H, TP309H, TP309HCb, TP310H, TP310HCb, TP310HCbN, TP316H, TP321H, TP347H, TP347HFG (fine grained) and TP348H. These modifications are intended for high-temperature service, particularly for superheaters and reheaters.

Yuhong Group ASME SA213 TP316H Stainless Steel Boiler Tube Datasheet

Outer Diameter: 31.75mm, 38.1mm, 44.45mm, 50.8mm, 57.15mm, 63.5mm, 76.2mm, up to 165.2mm
Wall Thickness: 2mm to 20mm
Length: Maximum: 34m/pc
All tubes match Grain Size <7 (ASTM E112)
100% Eddy Current Test (ASTM E426)
100% Hydrostatic Test (ASTM A1016 - 7Mpa/5s)

Quality Tests

Chemical Analysis
Mechanical Properties
- Tensile Requirement
- Hardness Requirement
- Flattening Test
- Flaring Test
Hydrostatic Test or Nondestructive Electric Test

Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Niobium	Other
TP316L	min: - max: 0.035	2.0	1.0	0.045	0.03	16	2~3	10	/	/
TP316H	min: 0.04 max: 0.1	2.0	1.0	0.045	0.03	16	2~3	10	/	/

Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HRB) max	Brinell (HBW) max
TP316L	485	175	35	90	192
TP316H	515	205	35	90	192

Note: TP316H also has a requirement for a grain size of ASTM No 7 or coarser.

Applications

Food preparation equipment
Laboratory benches & equipment
Coastal architectural panelling, railings & trim
Power Plant Boiler
Chemical containers, including for transport
Heat Exchanger
Oil and Gas
Petrochemical
Super Heater parts
Furnace
