Brand Name: | YUHONG |
Model Number: | ASTM A213 , ASME SA213 , TP321, TP321H , 1.4541 |
MOQ: | 1PC |
Price: | 1--10000 USD |
Packaging Details: | Bundle + Cap , Ply wooden case |
Payment Terms: | L/C, T/T |
Attribute | Value |
---|---|
Material Grade | TP321, TP321H, SUS321, 12X18H10, 12X18H12T, 1.4541 |
Material Standard | ASTM A213, ASME SA213, JIS G3459, EN10216-5, GOST 9941-81 |
NDT | ET, UT, HT, PT, PMI |
Size OD | 31.75 ~ 165.2mm |
Size Thickness | 2~20mm |
Size Length | Max.: 34m/pc |
The ASME SA213 TP321H specification covers seamless ferritic and austenitic stainless steel boiler, superheater, and heat-exchanger tubes. TP321H is a high carbon version of TP321 stainless steel, offering enhanced creep resistance and superior high-temperature strength.
These tubes are engineered for demanding high-temperature and high-pressure applications including boilers, superheaters, and heat exchangers in power plants, chemical processing facilities, and industrial environments requiring exceptional corrosion and heat resistance.
The TP321H grade features increased carbon content and titanium stabilization, ensuring structural stability at temperatures up to 900℃, making it ideal for extreme operating conditions.
Outer Diameter: 31.75mm to 165.2mm
Wall Thickness: 2mm to 20mm
Length: Maximum 34m per piece
Quality Assurance:
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Other |
---|---|---|---|---|---|---|---|---|---|---|
TP321 | min: - max: 0.08 |
2.0 | 0.75 | 0.045 | 0.03 | 17 | - | 9 | 0.1 | Ti=5(C+N) |
TP321H | min: 0.04 max: 0.1 |
2.0 | 0.75 | 0.045 | 0.03 | 17 | - | 9 | - | Ti=4(C+N) |
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness |
---|---|---|---|---|
TP321 | 515 | 205 | 40 | HRB max: 90 HBW max: 192 |
TP321H | 515 | 205 | 40 | HRB max: 90 HBW max: 192 |
Note: TP321H requires a grain size of ASTM No 7 or coarser.
