ASTM A213 T9 Alloy Steel Seamless Furnace And Heat Exchanger Tubes

ASTM A213 T9 Alloy Steel Seamless Furnace And Heat Exchanger Tubes

Brand Name: YUHONG
Model Number: ASTM A213 T9
MOQ: 1TON
Price: 1-10000 USD
Payment Terms: L/C, T/T
Supply Ability: 1000 tons/month
Detail Information
Place of Origin:
CHINA
Certification:
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Product:
Furnace And Heat Exchanger Tubes
Standard:
ASTM A213
Material:
T9
Size And Length:
According To Clients' Need
Packing:
Ply-wooden Case
Use:
For Heat Exchanger / Boiler / Furnaces,etc
Packaging Details:
Ply-wooden Case
Supply Ability:
1000 tons/month
Highlight:

T9 heat exchanger tube

,

A213 heat exchanger tube

,

Boiler heat exchanger pipe

Product Description
ASTM A213 T9 Alloy Steel Seamless Furnace And Heat Exchanger Tubes
Attribute Value
Product Furnace and Heat Exchanger Tubes
Standard ASTM A213
Material T9
Size and Length According to clients' need
Packing Ply-wooden Case
Use For Heat Exchanger / Boiler / Furnaces, etc
Product Description

ASTM A213 T9 Alloy Steel Seamless Furnace and Heat Exchanger Tubes

ASME SA213/ASTM A213 This specification covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes, designated Grades T5, TP304, TP321, etc. ASTM A213 T9 (SA213 T9) is a chromium-molybdenum (Cr-Mo) alloy steel specifically designed for high-temperature and high-pressure environments. Its unique composition (9% Cr, 1% Mo) provides excellent oxidation resistance, creep strength, and corrosion resistance.

Chemical Composition (%) max
  • Carbon: 0.15
  • Manganese: 0.30-0.60
  • Phosphorus: 0.025
  • Sulfur: 0.025
  • Silicon: 0.25-1.00
  • Chromium: 8.0-10.0
  • Molybdenum: 0.90-1.10
Mechanical Properties
  • Subcritical Annealing /Tempering Temperature, min or range: 1250 °F [675°C]
  • Tensile Strength, min.: 60ksi [415MPa]
  • Yield Strength, min.: 30ksi [205MPa]
  • Elongation in 2 in. or 50mm, min.: 30%
  • Brinell/Vickers: 179HBW/190HV
  • Rockwell: 89HRB
Advantages
  • Better Oxidation Resistance than T11/T22 at higher temps
  • Higher Creep Strength compared to carbon steel
  • Good Weldability (though pre/post-weld heat treatment is needed)
  • Cost-Effective compared to stainless steels (e.g., 304H, 321H) for certain temp ranges
Applications

Power Generation (Boilers & Superheaters)

  • Superheater & Reheater Tubes: T9 tubes withstand steam temperatures up to 650°C (1200°F) without excessive scaling
  • Boiler Tubes: Used in high-pressure boilers where carbon steel would fail due to oxidation
  • Heat Recovery Steam Generators (HRSGs): Resists thermal fatigue in combined-cycle power plants

Petrochemical & Refinery Applications

  • Furnace Tubes & Heat Exchangers: Handles sulfur-rich environments better than low-alloy steels
  • Catalyst Tubes in Refineries: Resists carburization and hydrogen attack at high temps

Chemical Processing Plants

  • High-Temperature Process Piping: Used where corrosive gases or steam are present
  • Thermal Cracking Units: Maintains strength under cyclic heating conditions
ASTM A213 T9 Alloy Steel Seamless Furnace And Heat Exchanger Tubes 0
