Stainless Steel ASTM A213 TP316L U Bend Tube For Heat Exchanger

Brand Name:	YUHONG
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China, Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

TP316L

Standard:

ASTM A213 , ASME SA213

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

TP316L Stainless Steel Heat Exchanger Tube

A213 Stainless Steel Heat Exchanger Tube

6mm heat exchanger stainless steel tube

Product Description

Stainless Steel ASTM A213 TP316L U Bend Tube For Heat Exchanger

Product Specifications

Attribute	Value
Material	TP316L
Standard	ASTM A213, ASME SA213
Ends	PE, BE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Description

The A213 TP316L is a high-quality austenitic stainless steel tube manufactured according to the ASTM A213 standard. This standard covers seamless ferritic and austenitic alloy steel tubes designed for high-temperature and high-pressure environments including heat exchangers, boilers, superheaters, and furnaces.

The U-Bend Tube is specifically engineered for applications requiring tight curvature, making it ideal for heat exchangers and condensers. TP316L is the low-carbon version of TP316, offering enhanced weldability and superior corrosion resistance for diverse industrial applications.

Chemical Composition

Chromium (Cr): 16.0% - 18.0%
Nickel (Ni): 10.0% - 14.0%
Molybdenum (Mo): 2.0% - 3.0%
Manganese (Mn): 2.0% max
Silicon (Si): 1.0% max
Carbon (C): 0.03% max (Key difference from TP316)
Phosphorus (P): 0.045% max
Sulfur (S): 0.03% max
Iron (Fe): Balance

Mechanical Properties

Tensile Strength: ~515 MPa (75,000 psi)
Yield Strength: ~205 MPa (30,000 psi)
Elongation: ~40% (in 50 mm gauge length)
Hardness: ~HRB 95

Physical Properties

Density: ~7.98 g/cm³
Melting Point: ~1375°C (2507°F)
Thermal Conductivity: ~16.2 W/m*K (at 100°C)
Specific Heat: ~500 J/kg*K
Modulus of Elasticity: ~200 GPa
Thermal Expansion: ~16.0 × 10^-6 /°C (20°C to 100°C)

Applications

Heat Exchangers
Condensers
Marine Applications
Chemical and Petrochemical Plants
Power Generation
Food and Dairy Industry
