ASTM A213 T11 Alloy Steel 6mm Heat Exchanger Tube For Tube Bundle

Brand Name:	YUHONG
Model Number:	Seamless tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

Standard:

ASTM A213 , ASME SA213

Ends:

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A213 T11 Heat Exchanger Tube

Heat Exchanger Tube For Tube Bundle

6mm Alloy Steel Heat Exchanger Tube

Product Description

ASTM A213 T11 Alloy Steel 6mm Heat Exchanger Tube For Tube Bundle

Product Specifications

Attribute	Value
Material Grade	T11
Standard	ASTM A213, ASME SA213
Ends	PE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Overview

ASME SA213 T11 alloy steel tubes are seamless, high-strength components optimized for moderate high-temperature environments (≤593°C). Their Cr-Mo composition balances oxidation resistance, creep strength, and fabricability, making them ideal for heat exchangers in power and petrochemical sectors. Compliance with rigorous ASME standards ensures reliability under demanding operational conditions.

Material Composition

Carbon (C): 0.05-0.15%
Manganese (Mn): 0.30-0.60%
Phosphorus (P): ≤0.025%
Sulfur (S): ≤0.025%
Silicon (Si): 0.50-1.00%
Chromium (Cr): 1.00-1.50%
Molybdenum (Mo): 0.44-0.65%

Mechanical Properties

Tensile Strength: ≥415 MPa (60,200 psi)
Yield Strength: ≥205 MPa (29,700 psi)
Elongation: ≥30% (in 2 inches)
Hardness: ≤85 HRB (Rockwell B)

Manufacturing Process

Seamless Fabrication: Produced via hot extrusion or cold drawing to eliminate weld seams, enhancing structural integrity for high-pressure applications.
Heat Treatment: Normalized at 900-950°C and tempered at 650-750°C to refine microstructure, balancing strength and ductility.

Dimensional Specifications

Outer Diameter (OD): 6.35-127 mm (0.25-5 inches)
Wall Thickness: 0.5-12.7 mm (0.02-0.5 inches)
Length: Customizable, typically up to 12 meters
Tolerances: Strict adherence to ASME standards for OD (±0.8%) and wall thickness (±10%)

Key Applications

Power Generation Plants: Boilers, superheaters, and heat recovery steam generators (HRSGs) where high temperatures and pressures are common.
Chemical and Petrochemical Industries: Heat exchangers, furnace tubes, and reactors requiring resistance to high temperatures and corrosive environments.
Refineries: Crude oil distillation units and hydroprocessing equipment where stable performance under extreme conditions is essential.
