EN 10216-2 P265GH Alloy Steel Seamless U Tube 28 Meters For Heat Exchanger PT Passed

Brand Name:	YUHONG
Model Number:	EN 10216-2 P265GH
MOQ:	100 KGS
Price:	YUHONG HOLDING GROUP CO., LTD
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Temperature Range:

High Temperature

Tube Type:

Heat Exchanger

Material Grade:

P265GH

Ends:

Size:

Customized

Standard:

Corrosion Resistance:

Pressure Rating:

Length:

Customized

Material:

Alloy Steel

Application:

Heat Exchanger

Testing:

UT, ET, HT, PMI

Wall Thickness:

Customized

Shape:

Round

Supply Ability:

5000 TONS PER MONTH

Highlight:

P265GH Alloy Steel Seamless U Tube

28m Alloy Steel Seamless U Tube

Product Description

EN 10216-2 P265GH Alloy Steel Seamless U Tube 28 Meters For Heat Exchanger PT Passed

Product Overview

Our P265GH Seamless U-Tubes are precision-engineered for heat exchanger applications, offering exceptional reliability and performance in demanding industrial environments.

Technical Specifications

Dimensional Range

Parameter	Range
Outer Diameter	6-114.3mm
Wall Thickness	1.0-12.0mm
Straight Length	Up to 28000mm
U-Bend Radius	1.5D-5D
Surface Finish	≤ Ra 3.2μm

Mechanical Properties

Property	Value
Tensile Strength	410-570 MPa
Yield Strength	≥265 MPa
Elongation	≥22%
Impact Energy at 20℃	≥27J

Chemical Composition of P265GH (EN 10216-2)

Element	C	Si	Mn	P	S	Cr	Mo	Ni
%	≤0.2	≤0.4	≤1.4	≤0.025	≤0.015	≤0.3	≤0.08	≤0.3

Key Features

Superior dimensional accuracy
Excellent surface finish
Uniform wall thickness
High pressure resistance
Outstanding heat transfer efficiency
Exceptional bend quality with minimal ovality

Manufacturing Process

Material selection and testing
Seamless tube production
Heat treatment
U-bending process
Post-bend heat treatment
NDT testing
Final inspection and packaging

Quality Assurance

100% Hydrostatic Testing
Ultrasonic Testing
Eddy Current Testing
X-Ray Testing for U-Bends
PMI Testing
Third-party Inspection Available

Applications

Heat Exchangers
Shell and Tube Heat Exchangers
Pressure Vessels
Power Generation Equipment
Chemical Processing Units
Oil & Gas Industry

Standards Compliance

EN 10216-2
ASTM Standards
ASME Standards
PED 2014/68/EU
AD 2000-Merkblatt

Yuhong Holding Group Co., Ltd., a leading manufacturer with 20 years of export experience to 80+ countries, ranks among China's top 5 finned tube exporters. Our newly established U-tube facility, alongside our existing 20,000 m² plant with 55 production lines and 110+ skilled professionals, demonstrates our commitment to comprehensive tube manufacturing solutions.

Yuhong Holding Group's commitment to quality is reflected in our comprehensive testing procedures and international certifications. Our new U-tube facility incorporates the latest bending technology and quality control systems, ensuring each tube meets the most stringent industry requirements.
