| Brand Name: | YUHONG |
| Model Number: | Seamless tube |
| MOQ: | 1 PC |
| Price: | 1 - 10000 USD |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000 Tons/Month |
| Attribute | Value |
|---|---|
| Material Grade | C6872T |
| Standard | JIS H3300 |
| Ends | PE |
| Testing | UT, ET, HT, PMI |
| Size | OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc |
| Application | Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle |
Copper alloys like C6872T offer excellent resistance to corrosion, especially in marine and chemical environments, making them ideal for use in heat exchangers exposed to aggressive fluids. The alloy is designed to provide good mechanical strength while maintaining the inherent flexibility and ductility of copper, allowing for high pressure and temperature tolerance.
The specific dimensions (e.g., diameter, wall thickness, and length) of JIS H3300 C6872T heat exchanger tubes depend on the application and client requirements, but they are generally available in a wide range of sizes to suit different heat exchanger designs.
| Grade | Cu | Zn | Al | As |
|---|---|---|---|---|
| JIS H3300 C6872T | 76.0-79.0% | Remainder | 1.8-2.5% | 0.02-0.06% |
| Grade | Tensile Strength | Yield Strength | Elongation | Hardness | Operating Temperature Range |
|---|---|---|---|---|---|
| JIS H3300 C6872T | ≥ 295 MPa | ≥ 105 MPa | ≥ 35% | 80-100 HV | Stable in environments up to 200°C (392°F) |
