ASME SB111 C71500 O61 Copper Alloy Steel Heat Exchanger Tube For Chemical Plants

Brand Name:	YUHONG
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

C71500

Standard:

ASTM B111 , ASME SB111

Ends:

PE , BE

Application:

Heat Exchangers, Condensers, Coolers, Etc.

Supply Ability:

10000 Tons/Month

Highlight:

ASME SB111 C71500 O61 Tube

Chemical Plants Heat Exchanger Tube

Product Description

ASME SB111 C71500 O61 Copper Alloy Steel Heat Exchanger Tube For Chemical Plants

Product Specifications

Attribute	Value
Material	C71500
Standard	ASTM B111, ASME SB111
Ends	PE, BE
Application	Heat Exchangers, Condensers, Coolers, Etc.

Product Overview

The ASME SB111 C71500 O61 Copper Alloy Steel Heat Exchanger Tube offers exceptional corrosion resistance, particularly in seawater or brackish water environments. This makes it ideal for marine applications, offshore systems, and desalination plants. The alloy's natural resistance to biofouling and pitting corrosion ensures long-term performance in challenging conditions.

Composition: C71500 is a copper-nickel alloy consisting of 70% copper and 30% nickel, with additional trace elements for enhanced performance.

Chemical Composition

Grade	Cu	Ni	Fe
ASME SB111 C71500	69-71%	29-33%	0.4-1.0%

Mechanical Properties

Grade	Temper	Yield Strength	Tensile Strength	Elongation
ASME SB111 C71500	O61 (annealed)	Approximately 125 MPa (18 ksi)	Approximately 350 MPa (51 ksi)	≥ 30%

Key Applications

Power Generation: Cooling systems in power plants, including condenser units and cooling towers using seawater or brackish water.
Desalination Plants: Heat exchangers and condensers in reverse osmosis (RO) and multi-effect distillation (MED) systems.
Chemical Processing: Heat exchangers handling aggressive chemicals or seawater, benefiting from superior corrosion resistance.
Offshore Oil & Gas: Cooling systems on offshore platforms where seawater durability is critical.
HVAC Systems: Industrial refrigeration and air conditioning in coastal environments with salty air exposure.
