ASME SB622 HASTELLOY C276 Nickel Alloy Steel Heat Exchanger Tube For Power Plants

Brand Name:	YUHONG
Model Number:	Seamless Tube
MOQ:	1PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

HASTELLOY C276

Standard:

ASTM B622 , ASME SB622

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

ASME SB622 Heat Exchanger Tube

HASTELLOY C276 Heat Exchanger Tube

Power Plants Heat Exchanger Tube

Product Description

ASME SB622 HASTELLOY C276 Nickel Alloy Steel Heat Exchanger Tube For Power Plants

Product Specifications

Attribute	Value
Material	HASTELLOY C276
Standard	ASTM B622, ASME SB622
Ends	PE, BE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Overview

ASME SB622 HASTELLOY® C-276 tubes are premium corrosion-resistant components designed for critical heat exchange applications, combining robust mechanical properties with exceptional durability in harsh chemical and thermal environments.

Material Composition

Primary Elements:
- Nickel (Ni): ~57% (balance)
- Chromium (Cr): 14.5-16.5%
- Molybdenum (Mo): 15-17%
- Tungsten (W): 3-4.5%
- Iron (Fe): 4-7%
Impurity Limits:
- Carbon (C): ≤0.01% (minimizes sensitization during welding)
- Silicon (Si): ≤0.08%, Manganese (Mn): ≤1%, Sulfur (S): ≤0.03%
- Cobalt (Co): ≤2.5%, Vanadium (V): ≤0.35%

Performance Characteristics

Excellent corrosion resistance in both oxidizing and reducing environments
Resists pitting, crevice corrosion, and chloride-induced stress corrosion cracking (SCC)
Performs well in sulfuric, hydrochloric, and acetic acids, chlorides, and sour gas (H₂S)

Mechanical Properties

Tensile Strength: ~100 ksi (690 MPa)
Yield Strength: ~45 ksi (310 MPa)
Elongation: ~45% (excellent ductility)
Thermal Conductivity: 9.8 W/m*K (at 100°C)
Coefficient of Thermal Expansion: 12.2 μm/m*K (20-100°C)
Density: 8.69 g/cm³
Non-Magnetic: Suitable for sensitive applications

Applications

Heat exchangers in semiconductor manufacturing (CVD systems)
Chemical recovery boilers in sulfur-rich environments
Offshore oil and gas production systems
Power plant heat exchangers and condensers
Chemical processing equipment
