ASTM A268 TP430 Stainless Steel Heat Exchanger Tube For Condensers

Brand Name:	YUHONG
Model Number:	Seamless tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Bundle + Cap , Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

TP430

Standard:

ASTM A268 , ASME SA268

ET, UT, HT, PT, PMI

Size OD:

6~203mm

Size Thickness:

0.5~25mm

Size Length:

Max.: 25m/pc

Supply Ability:

10000 Tons/Month

Highlight:

TP430 Stainless Steel Heat Exchanger Tube

Condensers Stainless Steel Heat Exchanger Tube

Product Description

ASTM A268 TP430 Stainless Steel Heat Exchanger Tube For Condensers

Product Specifications

Attribute	Value
Material	TP430
Standard	ASTM A268, ASME SA268
NDT	ET, UT, HT, PT, PMI
Size OD	6~203mm
Size Thickness	0.5~25mm
Size Length	Max.: 25m/pc

Product Overview

ASTM A268 TP430 Stainless Steel Tube is a ferritic stainless steel tube offering excellent corrosion resistance, oxidation resistance, and thermal stability at elevated temperatures. This material is widely used in heat exchangers, automotive exhaust systems, boilers, and furnace components.

TP430 provides superior performance in moderately corrosive environments and high-temperature conditions, making it ideal for chemical processing, petrochemical, power generation, and food processing industries. With excellent weldability, thermal cycling resistance, and mechanical strength, TP430 is a reliable choice for applications requiring durable heat transfer solutions under stress.

Chemical Composition (%)

Chromium (Cr): 16.0% - 18.0%
Nickel (Ni): 0.75% max
Manganese (Mn): 1.0% max
Silicon (Si): 1.0% max
Carbon (C): 0.12% max
Phosphorus (P): 0.04% max
Sulfur (S): 0.03% max
Iron (Fe): Balance

Mechanical Properties

Tensile Strength: ~ 480 MPa (70,000 psi)
Yield Strength: ~ 205 MPa (30,000 psi)
Elongation: ~ 25% (in 50 mm gauge length)
Hardness: ~ HRB 90

Physical Properties

Density: ~ 7.70 g/cm³
Melting Point: ~ 1400°C (2552°F)
Thermal Conductivity: ~ 25.4 W/m*K (at 100°C)
Specific Heat: ~ 460 J/kg*K
Modulus of Elasticity: ~ 200 GPa
Thermal Expansion: ~ 11.5 × 10^-6 /°C (20°C to 100°C)

Industrial Applications

Heat Exchangers
Automotive Exhaust Systems
Boilers and Furnace Components
Food and Dairy Processing
Petrochemical and Chemical Industry
Power Generation
Marine and Offshore
Industrial Heating Systems
