ASTM A268 TP409 Stainless Steel Welded Tubes For Industrial Heating Applications

Brand Name:	YUHONG
Model Number:	ASME SA268 TP409
MOQ:	1TON
Price:	1-10000 USD
Packaging Details:	Ply-wooden Case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Product:

Stainless Steel Welded Tubes

Standard:

ASTM A268 , ASME SA268

Material:

TP409

Size And Length:

According To Clients' Need

Application:

For Heat Exchanger / Reactors / Furnaces / Piping Systems,etc

Packing:

Ply-wooden Case

Supply Ability:

1000 tons/month

Highlight:

ASTM A268 Stainless Steel Welded Tubes

TP409 Stainless Steel Welded Tubes

Product Description

ASTM A268 TP409 Stainless Steel Welded Tubes For Industrial Heating Applications

Product Specifications

Attribute	Value
Product	Stainless Steel Welded Tubes
Standard	ASTM A268, ASME SA268
Material	TP409
Size and Length	Customized to client requirements
Application	Heat Exchangers, Reactors, Furnaces, Piping Systems
Packing	Ply-wooden Case

Product Description

ASTM A268 TP409 is a ferritic stainless steel tube manufactured to ASTM A268 standards, designed for demanding industrial applications. This low-carbon, chromium-based stainless steel offers exceptional corrosion resistance and high-temperature strength, making it ideal for environments requiring thermal stability and durability.

Chemical Composition (% max):

Chromium (Cr): 10.5% - 11.75%
Nickel (Ni): 0.75% max
Manganese (Mn): 1.0% max
Silicon (Si): 1.0% max
Carbon (C): 0.08% max
Phosphorus (P): 0.04% max
Sulfur (S): 0.03% max
Iron (Fe): Balance

Mechanical Properties:

Tensile Strength: ~450 MPa (65,000 psi)
Yield Strength: ~205 MPa (30,000 psi)
Elongation: ~25% (in 50 mm gauge length)
Hardness: ~HRB 85

Physical Properties:

Density: ~7.70 g/cm³
Melting Point: ~1400°C (2552°F)
Thermal Conductivity: ~25.5 W/m*K (at 100°C)
Specific Heat: ~460 J/kg*K
Modulus of Elasticity: ~200 GPa
Thermal Expansion: ~11.0 × 10^-6 /°C (20°C to 100°C)

Key Applications

Automotive Exhaust Systems: Ideal for exhaust pipes, mufflers, and catalytic converter tubes due to high-temperature oxidation resistance.
Heat Exchangers: Used in chemical processing and power generation for effective heat transfer.
Boilers and Furnace Components: Perfect for low-pressure steam boilers requiring thermal stress resistance.
Industrial Heating: Suitable for electric furnaces and thermal processing systems.
Food Processing: Used in pasteurizers and sterilizers due to non-reactivity with food.
Power Generation: Essential for heat recovery systems and boilers in power plants.
Petrochemical Industry: Used in reactors and tubes exposed to corrosive conditions.
