Heat Exchanger Tube
>
ASME SA249 TP304 Stainless Steel Welded Tubes For Heat Exchanger Equipment

ASME SA249 TP304 Stainless Steel Welded Tubes For Heat Exchanger Equipment

Brand Name: YUHONG
Model Number: ASME SA249 TP304
MOQ: 1TON
Price: 1-10000 USD
Packaging Details: Ply-wooden Case
Payment Terms: L/C, T/T
Detail Information
Place of Origin:
CHINA
Certification:
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Product:
Heat Exchanger Tubes
Standard:
ASME SA249
Material:
TP304
Size And Length:
According To Clients' Need
Use:
For Heat Exchanger / Boiler / Furnaces,etc
Packing:
Ply-wooden Case
Supply Ability:
1000 tons/month
Highlight:

TP304 Stainless Steel Welded Tubes

,

ASME SA249 Stainless Steel Welded Tubes

Product Description
ASME SA249 TP304 Stainless Steel Welded Tubes For Heat Exchanger Equipment
Product Specifications
Attribute Value
Product Heat Exchanger Tubes
Standard ASME SA249
Material TP304
Size and Length Customizable to client requirements
Use Heat Exchanger / Boiler / Furnaces
Packing Ply-wooden Case
Material Composition
Grade C Mn P S Si Cr Ni
TP304 0.08 2.00 0.045 0.030 1.00 18.0-20.0 8.0-11.0
Mechanical Properties
Grade Tensile Strength min Yield Strength min Elongation in 2" or 50mm min
TP304 75ksi (515 MPa) 30ksi (205 MPa) 35%
ASME SA249 specification covers nominal-wall-thickness welded tubes and heavily cold worked welded tubes made from austenitic steels, designed for boiler, superheater, heat exchanger, or condenser applications. TP304 stainless steel offers excellent corrosion resistance and mechanical properties with 18% chromium and 8% nickel content.
Key Features for Heat Exchanger Applications
  • Corrosion Resistance: Excellent resistance to fluids, chemicals, and high-temperature environments
  • High-Temperature Strength: Maintains structural integrity under thermal stress
  • Thermal Conductivity: Efficient heat transfer capabilities
  • Leak Resistance: Welded construction ensures tight seals
  • Pressure Resistance: Withstands high internal and external pressures
  • Hygienic Properties: Smooth surface prevents fouling and enables easy cleaning
Industrial Applications
  • Industrial heat exchangers in chemical plants, refineries, and power generation
  • HVAC systems for efficient heat exchange
  • Food and beverage processing equipment
  • Marine and offshore cooling systems
ASME SA249 TP304 Stainless Steel Welded Tubes For Heat Exchanger Equipment 0
