ASTM A249 TP316L Stainless Steel Welded Tube For Heat Exchanger

Brand Name:	YUHONG
Model Number:	Welded
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China, Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

TP316L

Standard:

ASTM A249 , ASME SA249

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A249 Stainless Steel Welded Tube

TP316L Stainless Steel Welded Tube

stainless steel heat exchanger tube Welded

Product Description

ASTM A249 TP316L Stainless Steel Welded Tube For Heat Exchanger

Product Specifications

Attribute	Value
Material	TP316L
Standard	ASTM A249, ASME SA249
Ends	PE, BE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Description

ASTM A249 TP316L Stainless Steel Heat Exchanger Tube is a high-performance tubing solution engineered for optimal heat transfer in corrosive environments. Manufactured from TP316L stainless steel, this product delivers exceptional corrosion resistance and structural integrity, making it ideal for applications requiring extensive welding without compromising performance.

Key Advantages:

Superior resistance to pitting and crevice corrosion
Excellent performance in chloride-rich environments
Maintains strength and durability in high-temperature applications

Chemical Composition

Grade	Cr	Ni	Mo	C
TP316L	16.00-28.00%	10.0-14.0%	2.0-3.0%	0.03% max

Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation	Hardness
TP316L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Industry Applications

Petrochemical Industry: Heat exchangers for crude oil refining, pipelines for aggressive chemicals
Power Generation: Steam boilers, condensate recovery systems
Marine Applications: Seawater cooling systems, ballast water treatment
Chemical Processing: Reactors, storage tanks for corrosive substances
Food & Beverage: Pasteurization equipment, brewing systems
Pharmaceutical: Processing equipment, API production
HVAC Systems: Chilled water systems, heat recovery
Pulp & Paper: Recovery boilers, chemical processing
Mining: Mineral processing, leaching systems
