Heat Exchanger Tube ASTM A312 TP316L For Power Generation

Brand Name:	YUHONG
Model Number:	Seamless Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China, Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

TP316L

Standard:

ASTM A312 , ASME SA312

Ends:

PE , BE

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

TP316L Heat Exchanger Tube

ASTM A312 Heat Exchanger Tube

Power Generation Heat Exchanger Tube

Product Description

Heat Exchanger Tube ASTM A312 TP316L For Power Generation

Product Specifications

Attribute	Value
Material	TP316L
Standard	ASTM A312, ASME SA312
Ends	PE, BE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Description

The Stainless Steel ASTM A312 TP316L Heat Exchanger Tube is engineered for optimal heat transfer performance in corrosive environments. Constructed from TP316L stainless steel, it delivers exceptional corrosion resistance and structural strength while maintaining weldability.

Key Features:

Low carbon content minimizes carbide precipitation
Maintains integrity under thermal and mechanical stress
Ideal for applications requiring frequent welding

Chemical Composition

Grade	Cr	Ni	Mo	C
TP316L	16.00-28.00%	10.0-14.0%	2.0-3.0%	0.03% max

Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation	Hardness
TP316L	≥ 170 MPa (25 ksi)	≥ 485 MPa (70 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Industrial Applications

Petrochemical Industry: Heat exchangers, reactors, and piping systems for petroleum processing
Power Generation: Steam boilers, condensers, and heat recovery systems
Marine Applications: Seawater cooling systems and marine heat exchangers
Chemical Processing: Reactors and exchangers for aggressive chemicals
Food & Beverage: Pasteurization and sterilization heat exchangers
Pharmaceutical: Corrosion-resistant processing equipment
HVAC Systems: Heating and cooling applications
Pulp & Paper: Recovery boilers and chemical processing exchangers
