ASME SA213 TP347H Seamless Stainless Steel Heat Exchanger Tube

Brand Name:	YUHONG
Model Number:	TP347, TP347H
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

TP347H, TP347

Standard:

ASME SA213, ASTM A213

Ends:

Testing:

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

Stainless Steel Heat Exchanger Tube Seamless

ASME SA213 TP347H Heat Exchanger Tube

sus Seamless Heat Exchanger Tube

Product Description

ASME SA213 TP347H Seamless Stainless Steel Heat Exchanger Tube

Product Specifications

Attribute	Value
Material Grade	TP347H, TP347
Standard	ASME SA213, ASTM A213
Ends	PE
Testing	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Description

TP347H seamless stainless steel heat exchanger tubes offer superior strength and creep resistance at elevated temperatures, making them ideal for high-stress applications. These tubes can withstand temperatures up to approximately 1,200°F (650°C) and are specifically designed for high-temperature environments with enhanced corrosion resistance and mechanical strength.

The TP347H grade contains higher carbon content and is stabilized with niobium to prevent carbide precipitation, ensuring long-term performance in demanding applications.

Chemical Composition

Grade	Cr	Ni	Nb	C
TP347H	17.0-19.0%	9.0-13.0%	≥ 10x C content, typically 0.2-0.7%	0.04-0.10%

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
TP347H	≥ 205 MPa (30 ksi)	≥ 515 MPa (75 ksi)	≥ 35% in 50 mm	Typically ≤ 95 HRB

Key Applications

Chemical Processing: Heat exchangers and reactors for handling high-temperature and corrosive chemicals
Power Generation: Boilers and superheaters for high-temperature steam service
Petrochemical Industry: Refinery applications with high-pressure steam and corrosive substances
Aerospace Industry: Exhaust components requiring high-temperature resistance
Industrial Heating: Furnaces and kilns with severe thermal cycling requirements
