Heat Exchanger Tube

Stainless Steel Heat Exchanger Tube, ASTM A213 TP304 (1.4301, SUS304), Petrochemical Application

All Category

Stainless Steel Heat Exchanger Tube

Duplex Stainless Steel Heat Exchanger Tube

Super Duplex Stainless Steel Heat Exchanger Tube

Nickel Alloy Steel Heat Exchanger Tube

Copper Alloy Steel Heat Exchanger Tube

Titanium Alloy Steel Heat Exchanger Tube

Alloy Steel Heat Exchanger Tube

Carbon Steel Heat Exchanger Tubes

Nickel Alloy Steel Boiler Tube

Duplex Stainless Steel Boiler Tube

Carbon Steel Boiler Tube

Sales Dept. (Marketing Director)

sales@steelseamlesspipe.com

+8613819835483

Contact Now

Stainless Steel Heat Exchanger Tube, ASTM A213 TP304 (1.4301, SUS304), Petrochemical Application

Brand Name:	YUHONG
Model Number:	TP304, 1.4301, SUS304
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case & Woven Bag
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China, Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material:

TP304, 1.4301, SUS304

Standard:

ASTM A213, ASME SA213, JIS G3463, GOST 9941, EN10216-5

Type:

Coil, Straight, U Bend

UT, ET, HT, PMI

Size:

OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc

Application:

Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle

Supply Ability:

10000 Tons/Month

Highlight:

ASTM A213 Stainless Steel Heat Exchanger Tube

ASME Stainless Steel Heat Exchanger Tube

1.4301 Seamless ss tube

Product Description

Stainless Steel Heat Exchanger Tube, ASTM A213 TP304 (1.4301, SUS304), Petrochemical Application

Product Specifications

Attribute	Value
Material	TP304, 1.4301, SUS304
Standard	ASTM A213, ASME SA213, JIS G3463, GOST 9941, EN10216-5
Type	Coil, Straight, U bend
NDT	UT, ET, HT, PMI
Size	OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application	Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle

Product Overview

Grade 304 (18/8 stainless steel) is the most versatile austenitic stainless steel, containing 18% chromium and 8% nickel. This composition provides excellent corrosion resistance, high formability, and superior mechanical properties, making it ideal for various industrial applications.

Chemical Composition

Grade	Cr	Ni	C	Mn	Si	P	S	N	Fe
304	18-20%	8-10.5%	0.08% max	2% max	1% max	0.045% max	0.03% max	0.10% max	Balance

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
304	Minimum 515 MPa (75,000 psi)	Minimum 205 MPa (30,000 psi)	Minimum 40% in 50 mm (2 inches)	Maximum 201 HB (Brinell hardness)

Corrosion Resistance

General Corrosion Resistance: Excellent resistance to atmospheric environments and many corrosive media
Pitting and Crevice Corrosion: Good resistance in moderately aggressive environments, though susceptible to chloride-induced corrosion

Industrial Applications

Chemical and Pharmaceutical: Chemical containers, transport tanks, heat exchangers, and pharmaceutical equipment
Water Treatment: Storage tanks, piping systems, and water treatment facilities
Heat Exchangers: Shell and tube heat exchangers for efficient heat transfer and durability
