Carbon Steel Low finned pipe ASTM A179 ASME SA179 For Heat Exchanger

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Material:

Fin Type:

Low Fin Type

Fin Thickness:

0.3mm

Fin Height:

1.24mm

Application:

Heat Exchanger

Highlight:

Low finned pipe

Carbon Steel finned pipe

SA179 finned heating pipe

Product Description

Carbon Steel Low Finned Pipe ASTM A179 ASME SA179 For Heat Exchanger

Product Specifications

Attribute	Value
Material	A179
Fin Type	Low Fin Type
Fin Thickness	0.3mm
Fin Height	1.24mm
FPI	23
Application	Heat Exchanger

Product Overview

The ASTM A179 / ASME SA179 Carbon Steel Low Fin Tubes are engineered for high-performance heat exchanger applications. These tubes are manufactured from low-carbon steel (ASTM A179), offering exceptional thermal conductivity, mechanical strength, and corrosion resistance. The low fin design enhances heat transfer surface area, significantly improving efficiency in heat exchangers, air coolers, and condensers.

Key Features

Base Tube Material: ASTM A179 / ASME SA179 Carbon Steel - Known for excellent thermal conductivity and mechanical properties, ideal for heat exchangers, boilers, and condenser systems.
Fin Type: Low Fin Tube Design - Features small-height fins (1.24mm) that increase surface area while reducing air-side resistance for higher thermal efficiency.
Application: Heat Exchanger, Condensers, Air Coolers - Enhanced heat transfer capabilities make these tubes perfect for industrial cooling applications.

Chemical Composition

Element	ASTM A179 Carbon Steel (Base Tube)
Carbon (C)	≤ 0.06%
Manganese (Mn)	0.27% - 0.63%
Phosphorus (P)	≤ 0.035%
Sulfur (S)	≤ 0.035%

Mechanical Properties

Property	ASTM A179 / ASME SA179 Carbon Steel
Tensile Strength	335 - 485 MPa
Yield Strength	≥ 205 MPa
Elongation	≥ 30%
Hardness	Brinell hardness: 160 - 190 HB

Advantages

Increased Heat Transfer Efficiency: Low fin design provides enhanced surface area for superior thermal performance.
Corrosion Resistance: Excellent durability in humid or corrosive environments.
Cost-Effective: Carbon steel construction offers economical performance without compromising quality.
Durability: Mechanically bonded fins withstand thermal cycling and mechanical stresses.
Compact Design: Low fin height allows for space-efficient heat exchanger configurations.

Applications

Air-Cooled Heat Exchangers in power generation, chemical plants, and oil refineries
Condensers for refrigeration and HVAC systems
Industrial cooling towers for efficient heat dissipation
Large-scale HVAC systems

Conclusion

The ASTM A179 / ASME SA179 Carbon Steel Low Fin Tubes provide an efficient solution for heat exchangers, delivering superior thermal performance, corrosion resistance, and long-term reliability. Their compact, cost-effective design makes them ideal for diverse industrial applications requiring high-efficiency heat transfer.
