ASTM A179 Carbon Steel Seamless Internally Finned Tubes For Air Coolers

Brand Name:	YUHONG
Model Number:	ASTM A179
MOQ:	Depend the size of finned tubes, 50-100PC
Price:	1-10000 USD
Packaging Details:	Ply-wooden Case With Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Product:

Fin Tubes Or Finned Tube

Type:

Low Fin Tubes / Integral Fin Tubes

Standard:

ASTM A179

Material:

Air-Cooled Heat Exchangers,Evaporators And Condensers,Radiators,Process Heating/Cooling,etc.

Packing:

Ply-wooden Case With Iron Frame

Supply Ability:

1000 tons/month

Highlight:

ASTM low fin tube dimensions

A179 low fin tube dimensions

Air Coolers internally finned tubes

Product Description

ASTM A179 Carbon Steel Seamless Internally Finned Tubes For Air Coolers

Product Specifications

Attribute	Value
Product	Fin Tubes or Finned Tube
Type	Low Fin Tubes / Integral Fin Tubes
Standard	ASTM A179
Material	A179
Use	Air-Cooled Heat Exchangers, Evaporators and Condensers, Radiators, Process Heating/Cooling, etc.
Packing	Ply-wooden Case With Iron Frame

Product Description

ASTM A179 Carbon Steel Seamless Internally Low Fin Tubes are designed for tubular heat exchangers, condensers, and similar heat transfer apparatus. These tubes are available in outside diameters ranging from 1⁄8 to 3 in. [3.2 to 76.2 mm].

Chemical Composition (%)

Grade	C	Mn	P	S
A179	0.06-0.18	0.27-0.63	0.035	0.035

Mechanical Properties

Grade	Tensile Strength, min	Yield Strength (0.2% Offset, min)	Elongation min.	Hardness, max
A179	47ksi (325 MPa)	26ksi (180 MPa)	35%	Rockwell: 72 HRB

Low fin tubes are enhanced heat transfer tubes specifically designed for applications like air coolers, where efficient heat exchange between a fluid inside the tube and air outside is required. These tubes feature a lower fin height compared to other finned tubes, making them ideal for compact and efficient heat exchanger designs.

Key Advantages

Increased surface area improves thermal efficiency and enhances heat transfer
Excellent corrosion resistance, wear resistance, and low contact thermal resistance
Compact design allows for smaller heat exchanger units and lower costs
Smooth fin surface minimizes fouling compared to high-fin tubes

Common Applications

Air-Cooled Heat Exchangers: Widely used in power plants, refineries, and chemical plants.

Evaporators and Condensers: Common in refrigeration and air conditioning systems.

Radiators: For automotive and industrial cooling systems.

Process Heating/Cooling: In chemical and petrochemical industries.
