Carbon Steel Low Fin Tube , ASME SA179 , Heat Exchanger Application

Brand Name:	YUHONG
Model Number:	Low Fin Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

SA179

Base Tube Material Standard:

ASME SA179

Type:

Straight Tube

Application:

Air Cooler, Cooling Tower, Heat Exchanger, Condenser

Fin Type:

Low Fin

Fin Material:

Aluminum , Copper , Stainless Steel , Carbon Steel

Supply Ability:

10000 Tons/Month

Highlight:

Carbon Steel Low Fin Tube

Low Fin Tube ASME SA179

Heat Exchanger Tube 3.2mm od

Product Description

Carbon Steel Low Fin Tube, ASME SA179, Heat Exchanger Application

Product Specifications

Attribute	Value
Base Tube Material Grade	SA179
Base Tube Material Standard	ASME SA179
Type	Straight Tube
Application	Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin Type	Low Fin
Fin Material	Aluminum, Copper, Stainless Steel, Carbon Steel

Product Description

Low Fin (Integral) tubing is an extruded tubing featuring short low fins that increase surface area while maintaining the same outside diameter as smooth tubes. These enhanced tubes are compatible with standard shell and tube baffles and tube sheets.

ASME SA179 covers seamless cold-drawn low-carbon steel tubes specifically designed for heat exchangers, condensers, and similar heat transfer equipment.

Technical Specifications

Chemical Composition

Carbon (C): 0.06-0.18%
Manganese (Mn): 0.27-0.63%
Phosphorus (P): ≤ 0.035%
Sulfur (S): ≤ 0.035%

Mechanical Properties

Tensile Strength: ≥ 325 MPa (47,000 psi)
Yield Strength: ≥ 180 MPa (26,000 psi)
Elongation: ≥ 35% (in 50 mm or 2 inches)

Dimensions

Description	Size Dimension
Tube OD	Min. 12.7mm / Max. 31.75mm
Tube thickness (plain section)	Min. 1.245mm / Max. 3.404mm
Fin pitch	19 – 26 – 27 – 28 – 30 – 36 fins per inch
Fin height	Max. 1.40mm
Tube length	Max. 25000mm

Key Advantages

High heat transfer efficiency with low-carbon steel construction
Excellent mechanical strength for heat exchanger applications
Enhanced durability through seamless construction
Cold-drawn process ensures dimensional accuracy
Suitable for low-corrosive environments

Applications

Shell and Tube Heat Exchangers
Condensers and Evaporators
Cooling Coils and Chillers
Process Coolers and Heat Recovery Units
Feedwater Heaters and Economizers
