Low Fin Tube ASME SB111 C70600 Copper Nickel Alloy Base Tube

Brand Name:	YUHONG
Model Number:	Low Fin Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Bast Tube Material Grade:

UNS C70600 O61 , Cu-Ni 90/10

Bast Tube Material Standard:

ASTM B111 , ASME SB111

Type:

Straight Tube

Application:

Heat Exchangers, Condensers, Coolers, Etc.

Fin Type:

Low Fin

Fin Material:

Copper

Supply Ability:

10000 Tons/Month

Highlight:

ASME SB111 Low Fin Tube

Low Fin Tube C70600

Copper Nickel Alloy Base Tube

Product Description

Low Fin Tube ASME SB111 C70600 Copper Nickel Alloy Base Tube

Product Specifications

Base Tube Material Grade	UNS C70600 O61, Cu-Ni 90/10
Base Tube Material Standard	ASTM B111, ASME SB111
Type	Straight Tube
Application	Heat Exchangers, Condensers, Coolers, Etc.
Fin Type	Low Fin
Fin Material	Copper

Product Description

Low fin tubes are heat exchanger tubes featuring short, integral fins on the outer surface. These fins are formed directly from the tube material, increasing surface area for heat transfer while maintaining structural integrity. Ideal for applications requiring enhanced heat transfer without significantly increasing tube diameter.

The ASME SB111 UNS C70600 O61 Copper-Nickel alloy offers excellent corrosion resistance to seawater and good fabricability. The 90/10 copper-nickel composition (90% copper, 10% nickel) provides strength, corrosion resistance, and ductility, making it suitable for marine, automotive, shipping, offshore, and power generation applications.

Low fin tubes provide superior heat transfer performance compared to plain tubes while maintaining the same diameter as the base tube, allowing use in standard shell and tube baffles and tube sheets.

Technical Specifications

Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Cu-Ni 90/10	2.0872	C70600

Grade Types

Type	UNS	EN	GB	ISO	JIS
Copper	C12200	CW024A	TP2	Cu-DHP	C1220
Copper	C12000	CW023A	TP	Cu-DLP	C1201
Admiralty Brass	C44300	CW706R	HSn70-1	CuZn28Sn1As	C4430
Admiralty Brass	C68700	CW702R	HAI77-2	CuZn20AI2Ass	C6870
Copper Nickel 90/10	C70600	CW352H	BFe10-1-1	CuNi10Fe1Mn	C7060
Copper Nickel70/30	C71500	CW354H	BFe30-1-1	CuNi30Mn1Fe	C7150

Chemical Composition

Cu	Mn	Pb	Fe	Zn	Ni
88.6 min	1.0 max	0.05 max	1.8 max	1 max	9-11 max

Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
0.323 lb/in³ at 68°F	2100°F	38	15	30%

Applications

Process Heaters

Waste Heat Boilers

Petrochemical Industries

Refinery Plant

Waste Heat Recovery Systems

Heating Equipment

Economizers

Heat Exchangers

Oil Coolers

Evaporators

Chillers
