Fully Killed Carbon Steel Embedded Fin Tube For Air Cooler ASME SA179

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Material:

Fin Type:

G/Embedded

Test:

HT, ET

Fin Material:

Al1060

Application:

Heat Exchanger, Air Cooler

Highlight:

Carbon Steel tube fins

Embedded tube fins

SA179 finned pipes

Product Description

Fully Killed Carbon Steel Embedded Fin Tube For Air Cooler ASME SA179

Material: A179

Fin Type: G/Embedded

Test: HT, ET

FPI: 9-13

Fin Material: Al1060

Application: Heat Exchanger, Air Cooler

ASME SA179 Fully Killed Carbon Steel Embedded Fin Tube for Air Coolers

This product is commonly used in air cooling systems and heat exchangers due to its excellent heat transfer characteristics, strength, and cost-effectiveness. The "fully killed" term refers to the carbon steel being treated during production to eliminate impurities, providing better mechanical properties and ensuring uniform quality.

Key Features

Property	Description
Material	Fully killed carbon steel (SA179) with embedded fin
Manufacturing Process	Seamless steel tubes with embedded fins for improved heat transfer
Fin Type	Embedded fins, typically helically wound, provide a large surface area
Heat Transfer Efficiency	High efficiency due to the embedded fin design
Corrosion Resistance	Moderate resistance suitable for non-corrosive to mildly corrosive environments
Temperature Resistance	Suitable for low to medium-temperature applications (up to 450°C or 850°F)
Strength	Good tensile strength and durability in air cooler applications

Chemical Composition

Element	Carbon (C)	Manganese (Mn)	Phosphorus (P)	Sulfur (S)	Silicon (Si)	Iron (Fe)
Percentage (%)	0.06 - 0.12	0.27 - 0.63	0.035 max	0.035 max	0.10 - 0.35	Balance

Mechanical Properties

Property	Value
Tensile Strength	415 MPa (60,200 psi)
Yield Strength	205 MPa (29,725 psi)
Elongation	35% min
Hardness (Rockwell B)	80 max
Modulus of Elasticity	190 GPa (27,500 ksi)

Applications

Air Coolers: Industrial cooling applications or HVAC systems
Heat Exchangers: Air-to-air and air-to-liquid heat exchangers
Chillers and HVAC Systems: Air conditioning or refrigeration systems
Oil and Gas Industry: Heat exchange in refineries and processing plants
Industrial Process Cooling: Chemical processing, power plants, manufacturing
Marine Applications: Compact cooling for naval vessels or offshore platforms

Advantages

Cost-effective compared to stainless steel or high-alloy materials
Efficient heat transfer with embedded fin design
Durable with improved mechanical properties
Widely available and easy to source
Versatile for different temperatures and pressures

Considerations for Use

May require protective coatings in humid or corrosive environments
Not suitable for extremely high-temperature applications (above 450°C)
Welding should be carefully performed to maintain integrity
