Embedded Finned Tube ASTM A179 With AL1060 Fins G Type Finned Tube For Air Cooler

Brand Name:	YuHong
Model Number:	ASTM 179
MOQ:	200~500 KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames and Pipe's both ends with plastic caps
Payment Terms:	T/T, L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, ISO, ASTM, SGS

Product Name:

Embedded/G Type Finned Tube

Base Tube Specification&Material:

ASTM A179

Fin Material:

ASTM B221 AL-1060

Fin Height:

＜17mm

Fin Thickness:

~0.4mm

Base Tube OD:

16~63mm

Fin Pitch:

2.1~5mm

Application:

Boiler/Air-cooled Condenser/Heat Exchanger

Supply Ability:

According to Clients' requirements

Highlight:

Air Cooler Embedded Finned Tube

Embedded Finned Tube ASTM A179

AL1060 Embedded Finned Tube

Product Description

Embedded Finned Tube ASTM A179 With AL1060 Fins G Type Finned Tube For Air Cooler

Product Specifications

Attribute	Value
Product Name	Embedded/G Type Finned Tube
Base Tube Specification & Material	ASTM A179
Fin material	ASTM B221 AL-1060
Fin Height	<17mm
Fin Thickness	~0.4mm
Base Tube OD	16~63mm
Fin Pitch	2.1~5mm
Application	Boiler/Air-cooled Condenser/Heat Exchanger

Product Overview

Embedded finned tube is a high-efficiency heat exchanger component featuring finned projections on the outer surface of the tube. These AL1060 aluminum alloy fins are embedded onto ASTM A179 steel tubes, creating an extended surface area that significantly enhances heat transfer performance.

Key Advantages

Enhanced thermal efficiency: AL1060 aluminum fins provide excellent heat conductivity
Corrosion resistance: Aluminum construction improves durability in harsh environments
Lightweight design: Aluminum fins reduce overall weight without compromising performance
Customizable configuration: Fin shape and size can be tailored to specific requirements
Energy efficient: Reduces operational costs through improved heat transfer

ASTM A179 Material Properties

The base tube material meets ASTM A179 specifications for seamless cold-drawn low-carbon steel tubes:

Chemical Composition

Carbon (C): 0.06-0.18%
Manganese (Mn): 0.27-0.63%
Phosphorous (P): 0.035% max
Sulfur (S): 0.035% max

Mechanical Properties

Tensile strength: 325 MPa (minimum)
Yield strength: 180 MPa (minimum)
Hardness: HRB 72 max
Elongation: 35% min

Industrial Applications

Air-cooled heat exchangers: Oil & gas, chemical processing, power generation
Condensers: Refrigeration systems and air conditioning units
Process heat exchangers: Oil refineries and chemical plants
Evaporators: Cooling applications in industrial systems
