Embedded G Fin Tube ASTM A179 Carbon Steel Fin Tube Fin Material Al1060 For Dry Air Cooler

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Material:

Fin Material:

Al1060, Al1100

Fin Type:

G Type, Embedded

Fin Tube Test:

HT/ET

Fin Thk:

0.4mm

Highlight:

Embedded G Fin Tube ASTM A179

Embedded G Fin Tube Carbon Steel

Product Description

Embedded G Fin Tube ASTM A179 Carbon Steel Fin Tube Fin Material Al1060 For Dry Air Cooler

Product Specifications

Attribute	Value
Material	A179
Fin Material	Al1060, Al1100
Fin Type	G Type, Embedded
Fin tube test	HT/ET
Fin thk	0.4mm
FPI	9-13

Product Overview

The Embedded G Fin Tube with ASTM A179 carbon steel base tubes and Al1060 aluminum fins is an efficient solution for dry air coolers. This design features embedded fins that enhance mechanical strength and thermal performance, making it ideal for industrial cooling systems.

Material Specifications

Component	Material
Base Tube Material	ASTM A179 Carbon Steel
Fin Material	Aluminum Al1060 (High Purity Aluminum)
Fin Type	Embedded G-Type

Chemical Composition

Base Tube (ASTM A179 Carbon Steel)

Element	Content (%)
Carbon (C)	≤ 0.06
Manganese (Mn)	0.27 - 0.63
Phosphorus (P)	≤ 0.035
Sulfur (S)	≤ 0.035

Fin Material (Al1060 Aluminum)

Property	Value
Tensile Strength	≥ 90 MPa
Yield Strength	≥ 35 MPa
Elongation	≥ 25%

Mechanical Properties

Base Tube (ASTM A179 Carbon Steel)

Property	Requirement
Tensile Strength (MPa)	≥ 325
Yield Strength (MPa)	≥ 180
Elongation (%)	≥ 35
Hardness	Typically ≤ 72 HRB

Key Features

Mechanical Strength: Embedded design ensures a tight bond between the fins and the tube for long-lasting performance.
Thermal Efficiency: Enhanced surface area for effective heat transfer.
Corrosion Resistance: High-purity aluminum fins provide excellent resistance to oxidation and environmental corrosion.
Durability: Ideal for high-temperature and high-pressure applications.
Lightweight: Aluminum fins reduce the overall weight of the cooling system.

Applications

Dry Air Coolers: Optimized for fluid cooling without water usage in arid or remote locations.
Heat Exchangers: Suitable for process cooling in industries such as power generation, petrochemicals, and refineries.
Oil & Gas: Used in air-cooled heat exchanger systems for hydrocarbon processing.
Chemical Plants: Efficient cooling solutions for reactors and other process equipment.

Advantages

High Thermal Performance: Maximized heat dissipation due to the embedded G-fin design.
Longevity: Resistant to environmental wear and tear, ensuring long-term reliability.
Cost-Efficiency: Aluminum fins and carbon steel tubes provide an economical and effective solution.
Customizable: Flexible dimensions and configurations to suit specific application needs.

Conclusion

The Embedded G Fin Tube with ASTM A179 Carbon Steel and Al1060 Aluminum Fins is a robust and efficient choice for dry air cooler applications. Its combination of thermal performance, mechanical strength, and corrosion resistance ensures reliable and effective cooling in industrial processes, making it a preferred solution for industries requiring sustainable and high-performance cooling systems.
