Embedded G Fin Tube ASTM A179 Fin Material Al1060 For Dry Air Cooler

Brand Name:	Yuhong
Model Number:	ASTM A179
MOQ:	100KGS
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

DNV, BV, PED, LR, ABS, TS, CCS

Material:

ASTM A179

Fin Material:

Al1060, Al1100

Fin Type:

Embedded Type

Applicatuon:

Air Cooler

Highlight:

Embedded G Fin Tube ASTM A179

Embedded G Fin Tube Al1060

Product Description

Embedded G Fin Tube ASTM A179 Fin Material Al1060 For Dry Air Cooler

Product Specifications

Material	ASTM A179
Fin Material	Al1060, Al1100
Fin Type	Embedded Type
Application	Air Cooler

Product Overview

Embedded G-type fin tubes with ASTM A179 carbon steel base tubes and Al1060 aluminum fins are specifically engineered for dry air coolers, offering superior heat dissipation and corrosion resistance. The G-type fin design maximizes surface area for optimal thermal performance while ensuring durable mechanical bonding.

Material Specifications

Base Tube Material:

Standard: ASTM A179
Type: Seamless Carbon Steel Tube
Applications: Ideal for heat exchangers requiring strength and efficient heat transfer

Fin Material:

Material: Aluminum Al1060 (High Purity Aluminum)
Type: Embedded G-type fins

Chemical Composition

Base Tube (ASTM A179 Carbon Steel)

Element	Carbon (C)	Manganese (Mn)	Phosphorus (P)	Sulfur (S)
Content (%)	≤ 0.06	0.27 - 0.63	≤ 0.035	≤ 0.035

Fin Material (Al1060 Aluminum)

Element	Aluminum (Al)	Silicon (Si)	Iron (Fe)	Copper (Cu)	Zinc (Zn)	Others (each)
Content (%)	≥ 99.60	≤ 0.25	≤ 0.35	≤ 0.05	≤ 0.05	≤ 0.03

Mechanical Properties

Base Tube (ASTM A179 Carbon Steel)

Property	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness
Requirement	≥ 325	≥ 180	≥ 35	Typically ≤ 72 HRB

Fin Material (Al1060 Aluminum)

Property	Tensile Strength	Yield Strength	Elongation
Value	≥ 90 MPa	≥ 35 MPa	≥ 25%

Key Features of Embedded G-Type Fins

Strong Bonding: Embedded design ensures tight mechanical fit between fins and base tube for excellent heat transfer and durability
Corrosion Resistance: High-purity aluminum (A1060) fins provide superior oxidation and environmental corrosion resistance
Enhanced Heat Transfer: G-type fins increase surface area for efficient cooling in dry air cooler systems
Lightweight: Aluminum fins reduce overall weight while maintaining high thermal conductivity

Applications

Dry Air Coolers: Industrial processes requiring fluid cooling without water
Heat Exchangers: Power plants, petrochemical refineries, and HVAC systems
Oil and Gas Industry: Air-cooled heat exchangers in remote or arid regions
Process Cooling: Industries requiring reliable and efficient cooling solutions

Product Advantages

High Thermal Efficiency: ASTM A179 base tubes and Al1060 aluminum fins ensure excellent heat transfer
Corrosion Resistance: Aluminum fins provide long-term protection against environmental factors
Durability: Resistant to mechanical stresses in high-temperature and high-pressure environments
Energy Efficiency: Maximizes heat dissipation to reduce overall energy consumption
Cost-Effectiveness: Economical solution for industrial cooling without compromising performance

Conclusion

The ASTM A179 Embedded G Fin Tube with Al1060 Aluminum Fins delivers high-performance cooling for dry air cooler applications. Its superior heat transfer capabilities, durability, and environmental resistance make it ideal for oil and gas, power generation, and chemical processing industries, ensuring optimal performance and long-term efficiency.
