ASME SA179 Embedded G Type Fin Tube For Air Cooler , Condenser

Brand Name:	YUHONG
Model Number:	Embedded G Type Fin Tube
MOQ:	1 PC
Price:	10-1000 USD/PC
Packaging Details:	STEEL FRAME CASE
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China, Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

SA179

Base Tube Material Standard:

ASME SA179, ASTM A179

Fin Material:

Aluminum, Carbon Steel

Max. Working Temperature:

750 °F（400 °C）

Bare Tube Diameter(MM):

16 - 63 Mm

Fin Pitch(MM):

2.1 - 5 Mm

Fin Height(MM):

<17 Mm

Fin Thick(MM):

~0.4 Mm

Supply Ability:

10000 TONS PER MONTH

Highlight:

Condenser Embedded G Fin Tube

Air Cooler Embedded G Fin Tube

ASME SA179 Embedded G Fin Tube

Product Description

ASME SA179 Embedded G Type Fin Tube For Air Cooler, Condenser

Product Specifications

Attribute	Value
Base Tube Material Grade	SA179
Base Tube Material Standard	ASME SA179, ASTM A179
Fin Material	Aluminum, Carbon Steel
Max. Working Temperature	750 °F (400 °C)
Bare Tube Diameter (MM)	16 - 63 mm
Fin Pitch (MM)	2.1 - 5 mm
Fin Height (MM)	<17 mm
Fin Thickness (MM)	~0.4 mm

Product Description

ASME SA179 Embedded G Fin Tube is a high-performance heat transfer component designed for enhanced thermal efficiency. The base tube is constructed from ASME SA179 carbon steel, renowned for its superior heat transfer properties and mechanical strength.

The fin strip is precisely wound into machined grooves on the tube surface and securely locked in place by back filling with base tube material. This innovative design delivers exceptional heat transfer efficiency at elevated tube metal temperatures.

Maximum Working Temperature: 750°F (400°C)

Fin Materials: Aluminum, Copper, Carbon Steel

Chemical Composition

Grade	C	Mn	P	S
SA179	0.06-0.18%	0.27-0.63%	0.035% max	0.035% max

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
SA179	≥ 180 MPa (26 ksi)	≥ 325 MPa (47 ksi)	Variable based on diameter	Typically ≤ 72 HRB

Industrial Applications

Power Generation: Used in heat exchangers for steam generation and cooling systems in power plants, enhancing overall efficiency and output.

Petrochemical Industry: Essential for refineries and chemical processing plants requiring high thermal efficiency and durability in corrosive environments.

HVAC Systems: Maximizes heat exchange in condenser and evaporator coils for improved energy efficiency in air conditioning and refrigeration units.

Oil and Gas Industry: Provides reliable performance in heat exchangers exposed to harsh marine conditions on offshore platforms.

Natural Gas Processing: Maintains process efficiency and reduces energy costs in high-performance heat exchangers.
