Embedded G Fin Tube , ASME SA179 Carbon Steel Seamless Tube With Al 1060, Air Cooler Application

Brand Name:	YUHONG
Model Number:	G Fin tube , Embedded Fin tube , Embedded G type fin tube
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Ply-Wooden Case +Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

A179, A192, A-1, C, A214, 10#, 20#, St35.8, St37.8

Base Tube Material Standard:

ASTM A178, ASTM A179, ASME SA179, ASTM A210, ASME SA210

Type:

Straight Tube , U Bend Tube , Coil Tube

Application:

Air Cooler, Cooling Tower, Heat Exchanger, Condenser

Fin Type:

G Fin Tube , Embedded Fin Tube , Embedded G Type Fin Tube

Fin Material:

Aluminum ,Copper, Stainless Steel, Carbon Steel

Supply Ability:

10000 tons/month

Highlight:

ASME SA179 G Fin Tube

G Fin Tube for Air cooler

Carbon Steel Seamless Tube

Product Description

Embedded G Fin Tube, ASME SA179 Carbon Steel Seamless Tube With Al 1060, Air Cooler Application

Product Specifications

Attribute	Value
Base Tube Material Grade	A179, A192, A-1, C, A214, 10#, 20#, St35.8, St37.8
Base Tube Material Standard	ASTM A178, ASTM A179, ASME SA179, ASTM A210, ASME SA210
Type	Straight Tube, U bend Tube, Coil Tube
Application	Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type	G Fin tube, Embedded Fin tube, Embedded G type fin tube
Fin Material	Aluminum, Copper, Stainless Steel, Carbon Steel

Product Overview

Yuhong Holding Group brings over 35 years of expertise in manufacturing steel pipes and fin tubes, specializing in applications for petrochemical, oil refinery, furnace, heating, boiler, heat exchanger, and air cooler systems. Our YUHONG brand products are exported to more than 85 countries worldwide and have earned an excellent market reputation.

Key Advantages

Enhanced Heat Transfer: The embedded G fin design increases surface area, improving heat transfer efficiency for better dissipation or absorption.
Increased Thermal Performance: Extended surface area enhances overall thermal performance with improved heat transfer rates.
Resistance to Fouling: Finned surface minimizes accumulation of contaminants, reducing maintenance frequency.
Mechanical Strength: Robust design resists damage and deformation during handling and operation.
Versatility: Suitable for HVAC systems, refrigeration units, industrial boilers, and process equipment.
Customization Options: Available in various fin densities, material compositions, and tube diameters.

Applications

Embedded G Fin Tubes are ideal for:

Air cooling heat exchangers
Steam coils and air preheaters
Finned tube heat exchangers and air coolers
Oil coolers and hydrogen coolers
Waste heat recovery systems and driers
Air conditioning and air heating systems
Steam condensers and generator coolers

Technical Specifications

Size Data

Base Tube/Core Tube O.D: 15.88-76.2mm
Fin height: 6-19mm
Fin thickness: 0.2-0.6mm
Fin pitch: Customizable
End: Plain Ends
No fin area on both sides: Customizable

ASME SA179 Chemical Composition (%)

C	Si	Mn	P	S	Result
0.06~0.18	/	0.27~0.63	≤0.035	≤0.035	/

ASME SA179 Tensile Test ASTM A370-20

Tensile Strength: Rm (Mpa)	Yield Strength: Rp 0.2(Mpa)	Elongation: A (%)
≥325	≥180	≥35
