Carbon Steel Embedded G Fin Tube , ASTM A179 With ASTM B209 Al 1060, Heat Exchanger Application

Brand Name:	YUHONG
Model Number:	G Fin tube , Embedded Fin tube , Embedded G type fin tube
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Ply-Wooden Case +Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

A179, A192, A-1, C, A214, 10#, 20#, St35.8, St37.8

Base Tube Material Standard:

ASTM A178, ASTM A179, ASME SA179, ASTM A210, ASME SA210

Type:

Straight Tube , U Bend Tube , Coil Tube

Application:

Air Cooler, Cooling Tower, Heat Exchanger, Condenser

Fin Type:

G Fin Tube , Embedded Fin Tube , Embedded G Type Fin Tube

Fin Material:

Aluminum ,Copper, Stainless Steel, Carbon Steel

Supply Ability:

10000 tons/month

Highlight:

Carbon Steel Embedded G Fin Tube

Embedded G Fin Tube ASTM B209

Al1060 ASTM A179 Heat Exchanger

Product Description

Carbon Steel Embedded G Fin Tube, ASTM A179 With ASTM B209 Al 1060, Heat Exchanger Application

Product Specifications

Attribute	Value
Base Tube Material Grade	A179, A192, A-1, C, A214, 10#, 20#, St35.8, St37.8
Base Tube Material Standard	ASTM A178, ASTM A179, ASME SA179, ASTM A210, ASME SA210
Type	Straight Tube, U bend Tube, Coil Tube
Application	Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type	G Fin tube, Embedded Fin tube, Embedded G type fin tube
Fin Material	Aluminum, Copper, Stainless Steel, Carbon Steel

Product Description

Yuhong Holding Group brings over 35 years of expertise in manufacturing steel pipes and fin tubes, specializing in applications for petrochemical plants, oil refineries, furnaces, boilers, heat exchangers, and air coolers. Our YUHONG brand products are exported to more than 85 countries worldwide and have earned an excellent market reputation.

Embedded G Type Fin Tube Features:

G-shaped fins significantly increase surface area for superior heat exchange efficiency
Enhanced thermal performance compared to traditional smooth tubes
Excellent resistance to fouling - minimizes dust and contaminant accumulation
Reduces maintenance requirements and maintains optimal performance

Technical Specifications

Base Tube/Core Tube O.D: 15.88-76.2mm Fin height: 6-19mm Fin thickness: 0.2-0.6mm Fin pitch: Customizable to customer requirements End: Plain Ends No fin area on both sides: As per customer specifications

Material Composition

ASTM A179 Chemical Composition (%)
C	Si	Mn	P	S	Cr	Ni	Mo	TI	Nb	Cu	Al	V	Co	Fe	Result
0.06~0.18	/	0.27~0.63	≤0.035	≤0.035	/	/	/	/	/	/	/	/	/	/

ASTM A179 Tensile Test ASTM A370-20
Tensile Strength: Rm (Mpa)	Yield Strength: Rp 0.2(Mpa)	Elongation: A (%)
≥325	≥180	≥35

Manufacturing Capabilities

20,000 square meters production facility
10 dedicated finning machines for Embedded G type fin tubes
Daily production capacity up to 8000 meters
Strategic location near Shanghai Port (less than 2 hours drive)
High rigidity construction for extreme temperature and pressure conditions

Applications

Tension wound finned tubes, embedded finned tubes and extruded finned tubes are essential components for air coolers in various industries:

Heat exchangers for power plants (electric, nuclear, thermal and geothermal)
Steam condensate systems
Chemical and petrochemical industry
Food processing plants and refrigeration technology
Industrial applications (steel mills, incinerators, gas compression facilities)
