ASME SA210 A1 Seamless Tube with Aluminum 1060 , Embeded G Fin Tube, Air Cooler Application

Brand Name:	YUHONG
Model Number:	Embedded G type fin tube
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ASME, PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Base Tube Material:

A179, SA179 , SA179N, SA179KN, A192, SA192, A1, C , A214 , SA214

Base Tube Standard:

ASTM A178, ASME SA178, ASTM A179, ASME SA179, ASTM A192, ASTM A210, ASME SA210, ASTM A214, ASME SA214

Fin Material Grade:

Aluminum 1050, 1060, 1100 , 6061, 6063

Applicable:

Air Coolering , Cooling Tower , Heat Exchanger

Testing:

Pressure Test, Firmness Test, Pulling Test

Length:

Max.: 34m/pc

Supply Ability:

10000 tons/month

Highlight:

asme sa210 base tube

asme sa210 g fin tube

cooling tower base tube

Product Description

ASME SA210 A1 Seamless Tube with Aluminum 1060 Embedded G Fin Tube

Product Specifications

Attribute	Value
Base Tube Material	A179, SA179, SA179N, SA179KN, A192, SA192, A1, C, A214, SA214
Base Tube Standard	ASTM A178, ASME SA178, ASTM A179, ASME SA179, ASTM A192, ASTM A210, ASME SA210, ASTM A214, ASME SA214
Fin Material Grade	Aluminum 1050, 1060, 1100, 6061, 6063
Applications	Air Cooling, Cooling Tower, Heat Exchanger
Testing	Pressure Test, Firmness Test, Pulling Test
Length	Max.: 34m/pc

Product Description

Yuhong Holding Group brings over 35 years of expertise in manufacturing steel pipes, tubes, and fin tubes for petrochemical, oil refinery, furnace, heating, boiler, heat exchanger, and air cooler applications. Our YUHONG brand products are exported to over 85 countries worldwide and have earned an excellent market reputation.

Embedded G Fin Tube Features

Also known as G type Finned Tube, providing perfect fin-to-tube connection
Manufactured by grooving tubes and inserting fins into helical grooves
Creates integral bond between fin and tube for superior durability
Ideal for high temperature applications and thermal cycling
Suitable for applications requiring regular fin-side cleaning

Manufacturing Capabilities

20,000 square meters production facility
10 dedicated finning machines for Embedded G type fin tubes
Daily extrusion capacity of 1800 meters
Strategic location near Shanghai Port (2 hours drive)

Technical Specifications

ASME SA210 Gr.A-1 Chemical Composition (%)

C	Si	Mn	P	S	Cr	Ni	Mo
≤0.27	≤0.10	≤0.93	≤0.035	≤0.035	/	/	/

ASME SA210 Tensile Test ASTM A370-20

Tensile Strength: Rm (Mpa)	Yield Strength: Rp 0.2(Mpa)	Elongation: A (%)
≥415	≥255	≥22

Quality Assurance

Chemical Composition Analysis
Mechanical Properties Testing
Hydrostatic Test
Pressure Test
Boroscopic Inspection
Firmness Test

Applications

Heat exchangers for power plants (electric, nuclear, thermal, geothermal)
Steam condensate systems
Chemical and petrochemical industry
Food processing plants and refrigeration technology
Industrial applications (steel mills, incinerators, gas compression facilities)
