Embedded G Fin tube, ASTM B163 Monel 400 Copper Nickel Seamless Tube with Al 1060, Oil Refining Project

Brand Name:	YUHONG
Model Number:	Monel 400 Fin tube , Copper Nickel Fin Tube
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ASME ,PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Base Tube Standard:

ASTM B163, ASME SB163 , ASTM B165, ASME SB165

Base Tube Grade:

Monel 400, Alloy 400, UNS NO4400, 2.4360

Fin Material:

ASME SB208 GR. 1060 , GR.1100

Fin Type:

Embedded G Type Fin Tube

Testing Of Fin Tube:

Pressure Testing , Firmness Testing , Pulling Testing

Application:

Air Cooler, Cooling Tower , Oil Refininging

Supply Ability:

10000 tons/month

Highlight:

embedded base tube

monel 400 base tube

monel 400 embedded g fin tube

Product Description

Embedded G Fin Tube, ASTM B163 Monel 400 Copper Nickel Seamless Tube with Al 1060 for Oil Refining Projects

Product Specifications

Attribute	Value
Base Tube Standard	ASTM B163, ASME SB163, ASTM B165, ASME SB165
Base Tube Grade	Monel 400, Alloy 400, UNS NO4400, 2.4360
Fin Material	ASME SB208 GR. 1060, GR.1100
Fin Type	Embedded G Type Fin tube
Testing	Pressure Testing, Firmness testing, Pulling Testing
Application	Air cooler, Cooling Tower, Oil refining

Product Description

Yuhong produces ASME SB163/ASTM UNS N04400 Monel 400 G Type Finned Tubes. Monel 400 is a nickel-copper alloy renowned for its excellent corrosion resistance, particularly in marine and chemical environments. These tubes are widely used in various industrial applications due to their unique properties.

ASME SB163 UNS N04400 Monel 400 tube is a Nickel Base Alloy Seamless Tube designed for heating applications. The alloy maintains excellent mechanical properties at both high temperatures (up to 1000°F) and subzero temperatures.

Monel 400 is hardened by cold working only and offers exceptional resistance to stress corrosion cracking in most freshwaters. Its corrosion-resistant properties make it ideal for marine applications and flowing seawater environments.

Chemical Composition (ALLOY 400/UNS N04400)

C	MN	P	S	Si	Cr	Ni	Cu	Al	Fe
.25max	1.5 max	-	.01 max	.5 max	-	63.0 min	27-33	2.30-3.15	2.5 max

Product Specifications

Product Form	Specification
Monel 400 Sheet/Plate	QQ N 286
Monel 400 Round Bar	ASME SB-865 AMS 4676 QQ N 286
Monel 400 Pipe	B165
Monel 400 Tube	B163, B165
Monel 400 Fittings	B366
Monel 400 Forgings	QQ N 286 AMS 4676

Fin Tube Specifications

Type	Description	Base Tube O.D. (mm)	Fin Pitch (mm)	Fin Height (mm)	Fin Thickness (mm)
Embedded	G-type fin tube	16-63	2.1-5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6-10	<17	0.2-0.4
Low fin tube	T-type fin tube	10-38	0.6-2	<1.6	~0.3

Production Capacity: More than 5000 meters per day
Available Lengths: Up to 25 meters
Tube Material Options: All types of material with minimum thickness of 1.00mm
