ASTM A312 TP304H Welded Helical Serrated Finned Tubes For Economizer Boiler

Brand Name:	YUHONG
Model Number:	ASTM A312 TP304H
MOQ:	Depend the size of finned tubes, 50-100PC
Price:	30-10000 USD
Packaging Details:	Ply-wooden Case With Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Product:

Finned Tube

Type:

Serrated Finned Tubes

Standard:

ASTM A312

Material:

TP304H Base Tubes, For High-temperature Service

Length:

According To Clients' Need

O.D.:

According To Clients' Need

For Large Equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, Etc

Packing:

Ply-wooden Case With Iron Frame

Supply Ability:

1000 tons/month

Highlight:

ASTM A312 Serrated Finned Tubes

Welded Helical Serrated Finned Tubes

Economizer Boiler Serrated Finned Tubes

Product Description

ASTM A312 TP304H Welded Helical Serrated Finned Tubes For Economizer Boiler

Product Specifications

Attribute	Value
Product	Finned Tube
Type	Serrated Finned Tubes
Standard	ASTM A312
Material	TP304H Base Tubes, For High-temperature Service
Length	According to clients' need
O.D.	According to clients' need
Use	For large equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Packing	Ply-wooden Case With Iron Frame

Product Description

Welded Helical Serrated Finned Tubes ASTM A312 TP304H For Economizer Boiler

Definition

Serrated spiral fin tubes are essential components of advanced heat exchangers. The combination of serrated fins and spiral configurations maximizes heat transfer while maintaining structural integrity. Tube and fin materials may be carbon, stainless steel, copper, ferritic alloy or austenitic alloy steel and can be of similar or dissimilar material combinations. The fin strip is cut or serrated at equally spaced intervals, with fins attached to the tube using high-frequency welding techniques, ensuring strong and durable connections while minimizing thermal distortion.

Details of ASTM A312 TP304H Base Tubes

ASTM A312 specification covers seamless, straight-seam welded, and heavily cold worked welded austenitic stainless steel pipe intended for high-temperature and general corrosive service. Welded (WLD) pipe is made using an automatic welding process with no addition of filler metal during the welding process.

Grades TP304H, TP309H, TP309HCb, TP310H, TP310HCb, TP316H, TP321H, TP347H, and TP348H are modifications of standard grades and are specifically intended for high-temperature service.

Chemical Composition (%)

Grade	C	Mn	P	S	Si	Cr
S30409	0.04-0.10	2.00	0.045	0.030	1.00	18.00-20.00

Mechanical Properties

Grade	Tensile Strength, min	Yield Strength (0.2% Offset, min)	Elongation min. %	Heat Treating Temperature min.
S30409	75ksi (515 MPa)	30ksi (205 MPa)	35%	1900°F [1040°C]

Advantages

The serrated fins create a larger surface area and promote turbulent flow, significantly improving heat exchange efficiency
The unique fin shape and spiral configuration enhance thermal performance compared to traditional fin tubes
Internal flow is more smooth with reduced flow resistance
Robust construction ensures strong joints, providing durability and reliability in demanding environments
Excellent corrosion resistance, wear resistance, and low contact thermal resistance
High stability and long service life
Simple and economical installation with minimal maintenance requirements

Applications

These finned tubes are suitable for a wide range of industrial applications:

Heat exchangers, boilers, furnaces and refineries: Ideal for oil coolers, condensers, and evaporators
Power Generation: Commonly used in power plants for efficient heat recovery and steam generation
HVAC Systems: Improves energy efficiency in heating, ventilation, and air conditioning systems
Chemical Processing: Critical for reactors and heat exchangers requiring optimal thermal performance

Specifications For Various Types Of Finned Tubes

Type	Description	Fin Specification (mm)
		O.D.	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tube	16-63	2.1-5	<17	~0.4
Extruded	Single metal / Combined metal	8-51	1.6-10	<17	0.2-0.4
Low fin tube / T-type fin tube		10-38	0.6-2	<1.6	~0.3
Bamboo tube / corrugated tube		16-51	8-30	<2.5	~0.3
Wound	L / KL / LL type fin tube	16-63	2.1-5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type fin tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3-25	5-30	0.8-3
H/HH type fin tube		25-63	8-30	<200	1.5-3.5
Serrated spiral fin tube		25-219	2-7	<38.1	0.9-2.0
Studed fin tube		25-219	8-30	5-35	φ5-20
