Heater HFW Serrated Fin Tube ASTM A312 TP304H With Stainless Steel Fins

Brand Name:	YuHong
Model Number:	ASTM A312 TP304H Serrated Finned Tube
MOQ:	200~500 KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Cases with Steel Frames and Pipe's both ends with plastic caps
Payment Terms:	T/T, L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ABS, BV, ISO, ASTM, SGS

Product Name:

Serrated Finned Tube / Serrated Spiral High Frequency Welding Finned Tube

Base Tube Specification&Material:

ASTM A312 TP304H

Fin Material:

Fin Height:

0.375″ To 1.25″

Fin Segment Width:

5/32″ Or 5/16″

Fin Thickness:

20ga (.035″) To 16ga (.060″)

Fin Pitch:

1 To 7 Fins Per Inch

Base Tube O.D.:

1.00″ To 12.75″ Outside Diameter

Applicatin:

Heat Exchangers, Air Preheaters, Boilers, And Reactors

Supply Ability:

According to Clients' requirements

Highlight:

Serrated fin tube

A312 fin tube

Heater tube fins

Product Description

Heater HFW Serrated Fin Tube ASTM A312 TP304H With Stainless Steel Fins

Product Specifications

Product Name	Serrated Finned Tube / Serrated Spiral High Frequency Welding Finned Tube
Base Tube Specification & Material	ASTM A312 TP304H
Fin material	S.S.
Fin Height	0.375″ to 1.25″
Fin Segment Width	5/32″ or 5/16″
Fin Thickness	20ga (.035″) to 16ga (.060″)
Fin Pitch	1 to 7 fins per inch
Base Tube O.D.	1.00″ to 12.75″ outside diameter
Application	Heat Exchangers, Air Preheaters, Boilers, and Reactors

Product Description

A serrated finned tube is a high-efficiency heat exchanger component designed with notched fins to increase surface area and improve heat transfer performance. The ASTM A312 TP304H variant combines high-carbon stainless steel construction with serrated fin design for optimal performance in demanding industrial environments.

Key Features

Superior Material: TP304H stainless steel offers excellent corrosion resistance, mechanical properties, and high-temperature strength
Enhanced Efficiency: Serrated fins maximize surface area and create turbulence for improved heat transfer rates
Durable Construction: Designed for long-term performance in high-temperature applications

Material Composition (ASTM A312 TP304H)

Element	Composition (%)
Carbon (C)	0.04 - 0.10
Manganese (Mn)	2.00 max
Phosphorus (P)	0.045 max
Sulfur (S)	0.030 max
Silicon (Si)	0.75 max
Chromium (Cr)	18.00 - 20.00
Nickel (Ni)	8.00 - 11.00
Nitrogen (N)	0.10 max
Iron (Fe)	Balance

Mechanical Properties

Property	Value
Tensile Strength	≥ 515 MPa (75,000 psi)
Yield Strength	≥ 205 MPa (30,000 psi)
Elongation (in 2 inches)	≥ 40%
Hardness (Brinell)	≤ 192 HB

Key Notes

TP304H is a high-carbon variant of 304 stainless steel optimized for high-temperature applications
Enhanced carbon content improves performance in elevated temperature environments
Widely used in heat exchangers, boilers, and other high-temperature industrial equipment

Industrial Applications

Heat Exchangers: Shell-and-tube, air-cooled, and other heat transfer systems
Boilers & Superheaters: High-temperature steam generation in power plants (exceeds 540°C/1000°F)
Petrochemical: Heat recovery systems, condensers, and reactors in harsh chemical environments
Power Generation: HRSGs and waste heat recovery systems for energy optimization
Oil & Gas: Gas coolers, preheaters, and heat transfer equipment in demanding operations
Waste Heat Recovery: Maximizing heat transfer from industrial exhaust streams
Aerospace: Heat exchangers and cooling systems requiring high strength and corrosion resistance
