ASME SA192 Serrated Type Welding Fin Tube Coil For Fired Heater

Brand Name:	YUHONG
Model Number:	Serrated, Helical Serrated
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Base Tube Material Grade:

SA192

Base Tube Material Standard:

ASME SA192 , ASTM A192

Type:

Serrated , Helical Serrated

Application:

Furnace Tube, Tube Coil , Radiate Tube , Convenction Tube , Fired Heater

Fin Type:

Serrated Fins

Fin Material:

Carbon Steel , Stainless Steel , Alloy Steel

Supply Ability:

10000 Tons/Month

Highlight:

Tube Coil Welding Fin Tube

Serrated Type Welding Fin Tube

ASME SA192 Welding Fin Tube

Product Description

ASME SA192 Serrated Type Welding Fin Tube Coil For Fired Heater

Product Specifications

Attribute	Value
Base Tube Material Grade	SA192
Base Tube Material Standard	ASME SA192, ASTM A192
Type	Serrated, Helical Serrated
Application	Furnace Tube, Tube Coil, Radiate Tube, Convenction Tube, Fired Heater
Fin Type	Serrated Fins
Fin Material	Carbon Steel, Stainless Steel, Alloy Steel

Product Description

ASME SA192 Serrated Type Welding Fin Tube, Tube Coil For Fired Heater

The tube is manufactured from carbon steel, specifically according to the ASME SA192 standard. This standard governs seamless carbon steel boiler and superheater tubes. ASME SA192 Standard is designed for high-pressure applications, offering excellent mechanical properties and resistance to pressure and temperature variations. ASME SA192 specifies the material composition for carbon steel that is suitable for high-pressure service.

The serrated fins are designed to increase the surface area of the tube, resulting in improved heat exchange efficiency. This is particularly useful in applications where space is limited, and enhanced heat transfer is essential.

Chemical Composition

Grade	C	Mn	P	S	Si
ASME SA192	0.06 - 0.18%	0.27 - 0.63%	0.035%	0.035%	0.10% (typical, not specified)

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
ASME SA192	Min. 325 MPa (47,100 psi)	Min. 180 MPa (26,100 psi)	Min. 35% (in 2 inches)	Typically ≤ 85 HRB

Key Characteristics

Seamless carbon steel tube construction
Designed for high-pressure and high-temperature applications
Commonly used in boiler, superheater, and heat exchanger systems
Strong mechanical properties for tensile strength and yield strength
Heat-treated for superior durability and reliability
Non-destructive testing ensures defect-free tubes

Applications

Boilers: In the power generation industry, these tubes are commonly used in boilers for steam generation. The serrated fins help increase the surface area for heat transfer, enhancing the efficiency of the heat exchange process.
Economizers: In economizers, these tubes help recover heat from the flue gas of a boiler to preheat the feedwater, increasing the boiler's overall efficiency.
Petrochemical Industry: These tubes can be used in the petrochemical industry for various heat transfer applications, such as heat recovery and cooling systems in refining and chemical processing units.
Air Cooled Heat Exchangers: In air-cooled heat exchangers, the tubes help dissipate heat effectively through the fins, enhancing the cooling process.
