Brand Name:	YUHONG
Model Number:	High Frequency weld fin tube, Welding fin tube, Fin Tube, Finned Tube, Solid Fin tube, HFW fin tube, Serrated Fin Tube
MOQ:	1PC
Price:	1--10000 USD
Packaging Details:	Bundle + Cap , Ply wooden case
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China,Korea

Certification:

ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Base Tube Material:

T12

Standard:

ASME SA213 , ASTM A213

Fin Material:

Stainless Steel

Fin Type:

High Frequency Welding Serrated Fin Tube

Length:

Max.: 34m/pc

Application:

Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils

Supply Ability:

10000 tons/month

Highlight:

Power Plants Welding Fin Tube

High Frequency Welding Fin Tube

ASME SA213 T12 Welding Fin Tube

Product Description

ASME SA213 T12 High Frequency Welding Fin Tube For Power Plants

Product Specifications

Attribute	Value
Base Tube Material	T12
Standard	ASME SA213, ASTM A213
Fin Material	Stainless steel
Fin Type	High Frequency Welding Serrated Fin Tube
Length	Max.: 34m/pc
Application	Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils

Product Description

The "T12" designation refers to Grade T12, a low-alloy steel containing 1.25% chromium and 0.5% molybdenum, offering excellent high-temperature strength.

Provides superior resistance to creep and oxidation, making it ideal for demanding power plant applications.

Chromium and molybdenum content enhances corrosion resistance in high-temperature environments.

Serrated fins increase surface area for optimal heat dissipation or absorption.

High-frequency welding process ensures cost-effectiveness and production efficiency.

Chemical Composition

Grade	Cr	Mo	C	Fe
ASME SA213 T12	0.8–1.25%	0.44–0.65%	0.05–0.15%	Balance

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness	Operating Temperature Range
ASME SA213 T12	415–585 MPa (60–85 ksi)	≥ 205 MPa (30 ksi)	≥ 24%	≤ 85 HRB	Up to 560°C (1040°F)

Applications

Heat Exchanger Units

Boilers

Waste Heat Recovery

Flue Gas Desulfurization

Superheaters & Reheaters

Heat Transfer Systems

Cooling Systems

Steam Generators

Desalination Plants

Air Heaters

Chilled Water Systems
