ASME SA335 P9 Alloy Steel High Frequency Welding Helical Solid Fin Pipe For Furnace

Brand Name:	YUHONG
Model Number:	ASME SA335 P9, HFW
MOQ:	100 KGS
Price:	Negotiate
Packaging Details:	Plywooden case with Iron Frame
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Product Name:

Finned Tube

Type:

High Frequency Welded Finned Tube

Application:

Heater Parts, Refrigeration Parts, Fluid Cooling

Dimensions:

88.9mm, 114.3mm, 168.3mm, Etc.

Length:

1-30000mm

Fin Height:

4-17mm

Tube Material:

Carbon Steel, Stainless Steel, Alloy Steel, Copper Etc

Fin Material:

Carbon Steel, Stainless Steel And Alloy Steel Etc

Warranty:

6 Months

Welding Area:

According To Actual Demand

Supply Ability:

4150 Ton Per Month

Highlight:

SA335 fin pipe

Solid fin pipe

P9 fin tubes for heat exchangers

Product Description

ASME SA335 P9 Alloy Steel High Frequency Welding Helical Solid Fin Pipe For Furnace

Product Specifications

Attribute	Value
Product name	Finned Tube
Type	High Frequency Welded Finned Tube
Application	Heater Parts, Refrigeration Parts, Fluid Cooling
Dimensions	88.9mm, 114.3mm, 168.3mm, etc.
Length	1-30000mm
Fin height	4-17mm
Tube material	Carbon Steel, Stainless Steel, Alloy Steel, Copper Etc
Fin material	Carbon Steel, Stainless Steel And Alloy Steel Etc
Warranty	6 Months
Welding area	According to actual demand

Product Overview

High-Frequency Welded ASME SA335 P9 Helical Finned Tubes are designed for extreme-temperature industrial furnace applications. These tubes combine chromium-molybdenum alloy durability with high-efficiency heat transfer, making them ideal for harsh environments.

Key Features

Material & Chemical Composition

Base Tube: ASME SA335 P9 Chromium-Molybdenum Alloy Steel (Cr: 8.5-9.5%, Mo: 0.90-1.10%)
Fin Material: High-grade stainless steel (AISI 304/316L) for corrosion resistance

Chemical Composition

Element	Cr	Mo	C	Mn	Si
Composition	8.5-9.5%	0.90-1.10%	≤0.15%	0.30-0.60%	0.50-1.0%

Compliant with ASME SA335 and ASTM A213 standards.

Mechanical Properties

Property	Value
Tensile Strength	≥620 MPa
Yield Strength	≥440 MPa
Elongation (A50)	≥20%
Operating Temperature	-20°C to 650°C

Manufacturing Process

High-Frequency Welding (HFW): Achieves 95% weld integrity between fins and base tube through automated spiral winding
Post-Weld Treatment: Shot blasting + anti-corrosion coating (zinc or epoxy) for enhanced durability
Quality Control: 100% hydrostatic testing (1.5x design pressure) and ultrasonic inspection

Applications

High-Temperature Furnaces: Cement kilns, steel reheating systems
Heat Recovery Units: Boilers, economizers, and air preheaters
Oil & Gas: Crackers, reformers, and sulfur recovery units

Advantages

Superior Heat Transfer: 4-7x higher efficiency than smooth tubes due to spiral fin design
Corrosion Resistance: Withstands acidic/sulfur-rich environments (pH 2-12)
Long Service Life: 2-3x lifespan over conventional welded tubes

FAQ

Q1: What is the lead time for bulk orders?

A: Standard lead time is 4-6 weeks for 20-ft container loads.

Q2: Can these tubes withstand thermal cycling?

A: Yes, the ASME SA335 P9 alloy ensures stability under repeated heating/cooling.

Q3: Are certifications available?

A: We provide ASME, ISO 9001, and EN 10204-3.1 certifications.

Why Choose Yuhong?

55 Production Lines: Fully automated HFW machines ensure consistent quality
Global Reach: Exported to 80+ countries with on-time delivery
Technical Support: 110+ engineers provide custom solutions for fin height (8-20mm) and pitch (4.5-15mm)

Email: jimmy@steelseamlesspipe.com

WhatsApp: +86 18892647377

Website: www.steelfintube.com
