ASME SA312 TP316 Seamless Steel Square Fin Tube For Boiler , Heat Exchanger

Brand Name:	YUHONG
Model Number:	H Fin Tube
MOQ:	1 PC
Price:	1 - 10000 USD
Packaging Details:	Ply-Wooden Case + Iron Frame
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China , Korea

Certification:

ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001

Material Grade:

TP316

Standard:

ASME SA312 , ASTM A312

Material:

Carbon Steel, Alloy Steel And Stainless Steel

Type Of Base Pipe:

Seamless Steel Pipe

Type Of Fins:

Single H / Double H Type

Application:

Widely Used For Boiler, Heat Exchanger, Condenser, Refrigerator, Economizer And Other Parts Of Heat Industry.

Supply Ability:

10000 Tons/Month

Highlight:

TP316 Square Fin Tube

TP316 Square Fin Tube For Boiler

Seamless Steel Square Tube ASME SA312

Product Description

ASME SA312 TP316 Seamless Steel Square Fin Tube For Boiler & Heat Exchanger

Product Specifications

Attribute	Value
Material Grade	TP316
Standard	ASME SA312, ASTM A312
Material	Carbon steel, Alloy steel and Stainless steel
Type of base pipe	Seamless steel pipe
Type of fins	Single H / Double H Type
Application	Widely used for boiler, heat exchanger, condenser, refrigerator, economizer and other parts of heat industry

Product Description

Grade TP316, also known as Type 316 stainless steel, is an austenitic chromium-nickel stainless steel containing molybdenum. This addition enhances the alloy's corrosion resistance, particularly against chlorides and other industrial solvents. TP316 is known for its excellent mechanical properties and high resistance to pitting and crevice corrosion in chloride environments.

ASME SA312 TP316 seamless steel square fin tubes are particularly effective in the chemical processing, oil and gas, marine, power generation, food and beverage, and pharmaceutical industries. Their outstanding performance in corrosive and high-temperature environments ensures long-term reliability and efficiency.

Chemical Composition

Grade	C	Ni	Mo	Mn	Si	N	C	P	S	Fe
TP316	16.0-18.0%	10.0-14.0%	2.0-3.0%	≤ 2.0%	≤ 1.0%	≤ 0.1%	≤ 0.08%	≤ 0.045%	≤ 0.03%	Balance

Mechanical Properties

Grade	Tensile Strength	Yield Strength	Elongation	Hardness
TP316	Minimum 515 MPa (75,000 psi)	Minimum 205 MPa (30,000 psi)	40% minimum in 50 mm	≤ 95 HRB (Rockwell Hardness B)

Key Features

Corrosion Resistance: Excellent resistance to general corrosion, pitting, and crevice corrosion, especially in chloride environments.
Mechanical Properties: Good mechanical properties at both room and elevated temperatures.
High-Temperature Resistance: Maintains stability and strength at high temperatures.
Weldability: Excellent weldability with or without filler metals.
Hygienic Properties: Non-reactive surface suitable for applications requiring high levels of hygiene.

Applications

Chemical Processing Industry: Heat exchangers, reactors and vessels, and piping systems dealing with corrosive chemicals and high temperatures.

Oil and Gas Industry: Offshore platforms, refinery equipment, and downhole tubing where exposure to corrosive elements is common.

Marine Applications: Seawater systems, shipbuilding, and desalination plants dealing with high-salinity water.
